Product Description

UV-PH-type UV-CTP plate is a new generation of UV-CTP plate that in order to meet the market requirements for speed and efficiency. The new formula photosensitive layer and the stability production process not only increase plate sensitivity, but also maintain the excellent performance of plate making and printing of Huaguang UV-P plate.

Huaguang UV-PH-type UV-CTP plate is the best choice for offset printing packaging and commercial printing with features of good developer adaptability, working well with UV-ink and long run length: 150.000 impressions with normal ink.

Characteristics
High-quality aluminum plate
Complex grain structure & dense oxidized layer
The substrate of hydrophilic treatment

Perfect coating formulation

Specifications
\t
Plate Type
\t
Commercial Positive UV-CTP plate
\t
Application
\t
Commercial sheet-fed and rotary press printing
\t
Substrate
\t
Electrochemically grained and anodized aluminum
\t
Gauge
\t
0.15/0.20/0.25/0.30/0.40 mm
\t
Image Color
\t
Blue
\t
Spectral Sensitivity
\t
350-460nm UV light,especially 400-410 UV laser
\t
Relative Sensitivity
\t
30-35 mw(Cron platesetter, Drum speed- High)
\t
Resolution
\t
2- 98% @ 250 lpi.( The difference between plate-making equipment will be different)
\t
Applicable Platesetter
\t
Main UV-CTP platesetters such as Cron, Luscher, Amsky, basysPrint.
\t
Color Change
\t
Blue-Green to Pale Green after exposed
\t
Recommended Processing Condition
\t
Temperature: 24±1℃;
Speed: 20-30s;
Washing temperature: room condition;
Drying temperature: 50℃;
Recommended developer: Huaguang PD Plate Developer(dilution: 1:3 or 1:4, replenishing rate: 100-150ml/㎡)
\t
Run Length
\t
150.000 impressions with normal ink.
\t
Safelights
\t
Yellow light
