Tobee Effluent Handling
$12,600
2BV Vacuum pump 2BV pumping water electric ring high pressure 15 KW water ring vacuum pump
- Category: >>>
- Supplier: Xiamen Mibay Technology Co. Ltd.
Share on (1600589368651):
Product Overview
Description
FAQ
product description:
2BV series water ring vacuum pumps are suitable for pumping the gases and steam. Its suction
pressure can reach 33mbar (abs) (i.e. 97 % vacuum degree). If the transformer oil is used as the operating liquid,
these pumps are called oil ring vacuum pump and the suction pressure can reach 6.7mbar (abs) (i.e. 99 %
vacuum degree). So the oil ring vacuum pumps can replace the reciprocated vacuum pumps completely. When
the liquid ring vacuum pumps work under the condition near the utmost vacuum for a long time, it is necessary to
couple with the cavitation protection pipe in order to get rid of the screaming so as to protect the pump. When the
2BV pumps are used as compressor, it should check the discharge pressure and select suitable motor power
because the motor power will be increasing along with the exhausting pressure.
Main Features:
1. The direct connection of the motor and pump with the same shaft saves space and convenient installation
2. Adopting mechanical seal as standard configuration, which can eliminate leakage and make the maintenance
convenient.
3. Operate steadily and the noise low to 62 dB
4. All the components are processed precisely by the CNC lathe, and the mechanical seal adopts international
famous brand such as John Crane or Bergman to ensure the precision.
5. Take NTN or NSK international famous brand bearing.
6. 2BV series liquid ring pump can be combined with ZJ series Roots vacuum pump to make roots and liquid ring
vacuum system. The ultimate vacuum can be 5pa. The 2BV liquid ring vacuum pump also can be coupled with
separator and heat exchanger to make closed circulation unit, which improved the safety and reliability by one
pump working, one pump backup
pressure can reach 33mbar (abs) (i.e. 97 % vacuum degree). If the transformer oil is used as the operating liquid,
these pumps are called oil ring vacuum pump and the suction pressure can reach 6.7mbar (abs) (i.e. 99 %
vacuum degree). So the oil ring vacuum pumps can replace the reciprocated vacuum pumps completely. When
the liquid ring vacuum pumps work under the condition near the utmost vacuum for a long time, it is necessary to
couple with the cavitation protection pipe in order to get rid of the screaming so as to protect the pump. When the
2BV pumps are used as compressor, it should check the discharge pressure and select suitable motor power
because the motor power will be increasing along with the exhausting pressure.
Main Features:
1. The direct connection of the motor and pump with the same shaft saves space and convenient installation
2. Adopting mechanical seal as standard configuration, which can eliminate leakage and make the maintenance
convenient.
3. Operate steadily and the noise low to 62 dB
4. All the components are processed precisely by the CNC lathe, and the mechanical seal adopts international
famous brand such as John Crane or Bergman to ensure the precision.
5. Take NTN or NSK international famous brand bearing.
6. 2BV series liquid ring pump can be combined with ZJ series Roots vacuum pump to make roots and liquid ring
vacuum system. The ultimate vacuum can be 5pa. The 2BV liquid ring vacuum pump also can be coupled with
separator and heat exchanger to make closed circulation unit, which improved the safety and reliability by one
pump working, one pump backup
Product Description
Industry application
Company Introduction
Xiamen star too mechanical and electrical co., LTD., founded in August 2009, the main focus on: vacuum pump, vacuum unit, vacuumsystem, helium mass spectrometer leak detector, molecular pump, lubricating oil, diffusion pump, vacuum measuring instrument,water ring vacuum pump, screw vacuum pump, roots pump, diaphragm pump, corrugated pipe and connector, vacuum parts, consumables,dry ice cleaning machines and other kinds of vacuum industry. More than 10 years in the company's technical efforts have become avacuum research, vacuum development, production of vacuum equipment professional company more than 1000 specifications, from roughvacuum to ultra high vacuum, from single pump to unit, from the acquisition of equipment to application equipment research anddevelopment production capacity. Vacuum products involve a number of scientific research to industrial applications, includinghigh energy physics, semiconductor industry, the chemical and physical analysis, vacuum coating, heat treatment, medical equipment, food packaging, building materials, electrical appliances, coal washing, vacuum deaeration, sewage treatment, hospitaland laboratory, electric power, metallurgy, textile, bathroom, blister, molds, freon, papermaking, and many other industrialapplications.
Exhibition
Company Profile
FAQ
1. How should i pay for my order ? what is the procession of this purchase ?
We accept TT by bank or other methods. You can do 30%prepayment at first, then we will start to make production.When the machine is ready , we will take pictures to you, and then youcan do the balance. I will send the machine to you after we got your payment.
2. How about your service after sales ? can yourengineer speak fluent english ?
We offer the service from you got the machine, including how to install the machine,how to usemachine, how to let machine work.,and so on. Usually ,we will teach you how to do by email or by skype our engineer who has many years of experience for cnc machine service . he can speak fulently in english .so he can slove the problem in short time.
3. Are you a factory or trading company?
We are the manufacturer . As only the machine made by ourself ,quality can be trusted, and most important thing is we can do better service after sales. we know how to fix the problem in each parts easliy. so welcome to visit our factory.
4. How long is the delivery time?
For standard machines, it would be 5-7 days; For non-standard machines and customized machines according to client s specific requirements, it would be 10 to 20 days.
5. How about the documents after shipment?
Aftershipment,will send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by client.
