Oem Gps Assembly Fr4 PCB Circuit Board Customized Electronic PCBA Manufacture Multilayer PCB Board ru 94v0 pcb circuit board

Layer

1~32 Layers

Material

FR4,CEM1,CEM3,Hight TG,Rogers,F4B,Taconic,FR1,FR2,94v0,Aluuminum

Order Quanyity

1~500,000

Board shape

Rectangular,Round,Slots,Cutouts,Complex,Irregular

Board Cutting

Shear,V-score,Tab-routed,Counter sunk

Board thickness

0.2~8.0mm,Flex0.01~0.25“

Copper weight

0.5oZ~12oZ

Solder mask

Double-sided green LPI,Also support red,white,yellow,blue,black,purple,etc

Silk screen

Double-sided or single-sided in white,yellow,red,black,or negative

Min line width/space

0.06/0.06mm

Max board dimensions

25.6 inch*43.3 inch or 650mm*1100mm

Min drill hole diameter

0.1mm

Surface finish

HASL,ENIG,Immission Ti,Immisson Silver,OSp,ENEPIG,etc

Board thickness tolerance

±10%

Minimal slot width

0.12"，3.0mm，or 120 mils

V-score depth

20~25% of board thickness

PTH Wall Thinckness

>0.025mm

PTH Hole Dia Tolerance

±0.076mm

Non PTH Hole Dia Tolerance

±0.05mm

Hole Position Deviation

±0.076mm

Sink holes

Yes

Quality Standard

IPC-A600F/MIL-STD-1050D

Design file format

Ki-CAD,Pro-E Gerber RS-274X,274D,Eagle and AutoCAD'S DXF,DWG

Assembly Options

Surface Mount ( SMT ) . Thru-Hole ( THT ) . Box building , COB , Conformal Coating , Potting and Encapsulations , IC Programming &
Marking Gringing & Lettering

Types of Solder

Leaded and Lead-free (RoHS Compliant ) PCB assembly services

Stencils

Laser cut stainless steel stencils

Minimum Order

1 pieces

Component Size

Passive Component : we can accept components as small as 01005 . 0201 BGA : we have the ability to handle BGA of 0 . 25mm pitch
with X-ray testing Fine Pitch Parts : we can assemble 0 . 25mm fine pitch parts . POP ( Package on Package ) . QFP CCGA , CSP etc
Max Component Height : 25mm ( SMT ), Top 120mm / Bot 15mm ( Wave-Solder )

Component Package

We accept parts in Reels , Cut Tape , Tube &Tray , Loose Parts and Bulk

Board Dimension

Min Board Size : No LimitedMax Board Size : 680x500mm

Board Shape

We can assemble boards in Rectangular, Circular and any Odd Shapes

Board Type

Rigid PCB . Flexible PCB,Rigid-flex PCB, Metal PCB

Repair& Rework

Repair and rework accepted , Our BGA reballing service with which we can safely remove the misplaced BGA , reball it and put it
back on the PCB correctly . It is cost-effective

Testing

ICT . AOI , X-Ray , Function Test ( FCT ) , Aging Test

OutPut

12 SMT lines and 5 DIP lines

Quality Standard

IPC-A-610E , IS0 13485 : 2003 , ISO 16949 : 2011 , ISO 14001 : 2004
