Hot selling DC to AC inverter 24v to 380v 3kw

Product Overview

Description

Datasheet	SPF 3000TL LVM-ES
Battery Voltage	48VDC
Battery Type	Lithium/Lead-acid
INVERTER OUTPUT
Rated Power	3000VA/ 3000W
Parallel Capability	Yes, 6 units maximum
AC Voltage Regulation (Battery Mode)	100Vac/110Vac/120Vac @ 50/60Hz
Surge Power	6000VA
Efficiency (Peak)	93%
Waveform	Pure sine wave
Transfer Time	10ms typical,20ms Max
SOLAR CHARGER
Maximum PV Array Power	4000W
MPPT Range @ Operating Voltage	120VDC ~ 250VDC
Number of Independent MPP Trackers/ Strings Per MPP Tracker	1/1
Maximum PV Array Open Circuit Voltage	300VDC
Maximum Solar Charge Current	60A
Maximum Efficiency	97%
AC CHARGER
Charge Current	40A
AC Input Voltage	120VAC
Selectable Voltage Range	95-140VAC (For Personal Computers) ; 65-140VAC (For Home Appliances)
Frequency Range	50Hz/60Hz (Auto sensing)
PHYSICAL
Protection Degree IP20
Dimension (W/H/D)	320/470/135mm
Net Weight (kgs)	12
OPERATING ENVIRONMENT
Humidity	5% to 95% Relative Humidity(Non-condensing)
Operating Temperature	0°C - 50°C
Storage Temperature	-15°C - 60°C
