harvester heads 360mm cutting timber harvester head for 12-15 ton excavator
- Category: Forestry Machinery >>>
- Supplier: Guangxi,Xuvol,Construction,Machinery,Equipment,Co.,Ltd.
Share on:
Product Overview
Description
harvester heads 360mm cutting timber harvester head for 12-15 ton excavator
Product Description
Tree Cutter Harvesters Forestry Machinery
The excavator tree harvester felling machine is designed for R & D in logging, and is widely used in North America, South America, Europe, Australia and other places.
It is convenient for logging construction and greatly reduces the cumbersome labor. Strengthen the lower frame, on the car protection,
dust-proof design so that the vehicle in the wood and bamboo when the life and reliability greatly improved,
the cab specifically with the iron wire frame and glass for the driver to provide comprehensive protection, saw-off logs and clean braches as well
| weight | 700±20kg | Length | 1500+50mm |
| width | 850-1250mm | Maximum cutting diameter | 350±10mm |
| chain speed | 50±5 m/s | Clamping Minimum Diameter | 40 ±5 mm |
| Maximum pruning diameter | 350±10mm | Feed wheel | 2 rollers |
| Feed motor displacement | 2*398 cc | Feeding speed | 0 to 5±1m/s |
| Feeding Traction | 15±5 KN | Debranching knife | 4+1 |
| Workflow | 180L/min | Work pressure | 23±2 Mpa |
| Control System | Support built-in intelligent system | Matching excavator models | 12 to 15 Ton |
Widely used on 90% of global excavator brands, exported to Japan, Vietnam, Indonesia, England and other countries.
Tree harvester with stretch film and Wooden box
The standard package is wrap with stretch film and tied on wooden pallets. We will do special package by your requirements if you need.
