General information
|
Type
|
CPU / Microprocessor
|
Market segment
|
Desktop
|
Family
|
|
Model number ?
|
|
CPU part numbers
|
CM8070804491414is an OEM/tray microprocessor
BX8070811600Kis a boxed processor (English version)
BXC8070811600Kis a boxed processor (Chinese version)
|
Frequency ?
|
3900 MHz
|
Maximum turbo frequency
|
4900 MHz (1 core)
4600 MHz (all cores)
|
Low power frequency
|
800 MHz
|
Bus speed ?
|
8 GT/s DMI
|
Clock multiplier ?
|
39
|
Package
|
1200-land Flip-Chip Land Grid Array
|
Socket
|
Socket 1200
|
Size
|
1.48" x 1.48" / 3.75cm x 3.75cm
|
Introduction date
|
March 16, 2021
|
Price at introduction
|
$262
|
S-spec numbers
|
Part number
|
ES/QS processors
|
Production processors
|
|
QWJS
|
SRKNU
|
BX8070811600K
|
|
+
|
BXC8070811600K
|
|
+
|
CM8070804491414
|
|
+
|
Unknown
|
+
|
|
|
Architecture / Microarchitecture
|
Microarchitecture
|
Rocket Lake
|
Processor core ?
|
Rocket Lake-S
|
Manufacturing process
|
0.014 micron
|
Data width
|
64 bit
|
The number of CPU cores
|
6
|
The number of threads
|
12
|
Floating Point Unit
|
Integrated
|
Level 1 cache size ?
|
6 x 32 KB 8-way set associative instruction caches
6 x 48 KB 12-way set associative data caches
|
Level 2 cache size ?
|
6 x 512 KB 8-way set associative caches
|
Level 3 cache size
|
12 MB 16-way set associative inclusive shared cache
|
Physical memory
|
128 GB
|
Multiprocessing
|
Uniprocessor
|
Extensions and Technologies
|
MMX instructions
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
AVX2 / Advanced Vector Extensions 2.0
AVX-512 / Advanced Vector Extensions 512
BMI / BMI1 + BMI2 / Bit Manipulation instructions
Deep Learning Boost
F16C / 16-bit Floating-Point conversion instructions
FMA3 / 3-operand Fused Multiply-Add instructions
Gaussian Neural Accelerator 2.0
SHA / Secure Hash Algorithm extensions
EM64T / Extended Memory 64 technology / For Intel 64 ?
HT / Hyper-Threading technology ?
VT-x / Virtualization technology ?
VT-d / Virtualization for directed I/O
TBT 2.0 / Turbo Boost technology 2.0 ?
|
Security Features
|
NX / XD / Execute disable bit ?
MPX / Memory Protection Extensions
TXT / Trusted Execution technology
SMAP / Supervisor Mode Access Prevention
SMEP / Secure Mode Execution Protection
UMIP / User Mode Instruction Prevention
|
Low power features
|
Core C1/C1E, C3, C6, C7, C8, C9 and C10 states
Package C3, C6, C7, C8, C9 and C10 states
Display Power Saving Technology
Graphics Core Power Saving Technologies
Enhanced SpeedStep technology ?
|
Integrated peripherals / components
|
Display controller
|
|
Integrated graphics
|
GPU Type: For Intel UHD 750
Microarchitecture: For Intel Xe
Execution units: 32
Base frequency (MHz): 350
Maximum frequency (MHz): 1300
|
Memory controller
|
The number of controllers: 1
Memory channels (per controller): 2
Memory channels (total): 2
Channel width (bits): 64
Supported memory: DDR4-2933, DDR4-3200
DIMMs per channel: 2
Maximum memory bandwidth (GB/s): 51.2
|
Other peripherals
|
Direct Media Interface 3.0 (8 lanes)
PCI Express 4.0 interface (16 lanes for discrete graphics, 4 lanes for storage)
|
Electrical / Thermal parameters
|
Minimum/Maximum operating temperature ?
|
0°C (case) - 72.1°C (case)
100°C (junction)
|
Thermal Design Power ?
|
125 Watt
|
Notes on For Intel Core i5-11600K
|
The processor has unlocked clock multiplier
Configurable TDP-down feature is supported. The CPU operates at 3.6 GHz and has 95 Watt TDP in TDP-down mode
For Intel Optane memory is supported
DDR4-3200 memory is not supported on platforms, based on For Intel 400-series chipsets
The processor has the following security, data protection and/or software features: For Intel Boot Guard, Identity Protection technology, OS Guard, Secure Key and vPro technology.
The CPU is compatible with DirectX 12.1, OpenGL 4.5 and OpenCL 3.0 APIs.
The graphics unit has the following software features enabled: For Intel Quick Sync Video, Clear Video technology, Clear Video HD technology and InTru 3D technology.
|
