1000 degree light calcium silicate insulation board for high temperature pipeline
- Category: Construction & Real Estate >>>
- Supplier: Inner,Mongolia,Cscec,Asia,Pacific,Building,Materials,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
Composition:
xonotlite crystals, floating beads and reinforcing fibers, so the product does not contain asbestos.
Block Sizes and Dimensional Tolerances: | ||||
Length * width | Thickness（mm） | remarks | ||
600*1200（±3mm) | 10mm-130mm | The specific thickness is customized by the customer | ||
1200*1200(±3mm） | 10mm-130mm | The specific thickness is customized by the customer | ||
Application fields:
1. Petroleum smelting
2. Energy and chemical industry
3. Electric power metallurgy
4. Electrolytic aluminum tank cement kiln
5. High temperature pipeline
6. Steel structure fireproof interior and exterior wall insulation decoration
7. Energy saving, thermal insulation works of equipment
2. Energy and chemical industry
3. Electric power metallurgy
4. Electrolytic aluminum tank cement kiln
5. High temperature pipeline
6. Steel structure fireproof interior and exterior wall insulation decoration
7. Energy saving, thermal insulation works of equipment
Main features:
It is superior to the national standard gb/t10699-2015 calcium silicate thermal insulation products and the standard requirements of 1000 ℃ calcium silicate thermal insulation materials.It is a class A1 non combustible material.
1. High heat-resistant temperature, the maximum heat-resistant temperature reaches 1100 ℃, and the linear shrinkage is small
2. With low thermal conductivity and strong thermal insulation performance, it is a high-quality, efficient and energy-saving
product.
3. Low bulk density (up to 160kg/m at least ³）、 High strength
product.
3. Low bulk density (up to 160kg/m at least ³）、 High strength
4. Good durability, corrosion resistance, long-term use, no ceramic fiber felt similar to the pulverization.
5. It can cut and saw, and it is convenient for construction.
5. It can cut and saw, and it is convenient for construction.
6. It does not contain carcinogens asbestos, sulfur, chlorine and other toxic substances and other organic binders.
7. The material absorbs water, but it can also be used after drying
7. The material absorbs water, but it can also be used after drying
Technical Parameters | ||||||||||
Description | Unit | YT160 | YT250 | YT320 | YT431 | |||||
Bulk Density (kg/ m³) | Kg/m³ | 139(±10%) | 260(±10%) | 320(±10%) | 430(±10%) | |||||
Pressure Strength | MPa | 0.35 | 1.52 | 4.72 | 4.43 | |||||
Flexural Strength | MPa | 0.72 | 1.06 | 2.88 | 4.79 | |||||
Thermal Conductive | W/m.k | 0.047（room temperature 300℃ | 0.078（300℃） | 0.042（Hot surface 300℃） | 0.072（Hot surface 300℃） | |||||
0.05（room temperature 600℃） | 0.072（Hot surface 600℃） | 0.076（Hot surface 600℃） | ||||||||
0.072（room temperature 1000℃ | 0.105（Hot surface 1000℃） | 0.089（Hot surface 1000℃） | ||||||||
Temp limit | ℃ | 1050 | 1050 | 1050 | 1050 | |||||
Linear Shrinkage | % | 0.6（1000℃*16h) | 0.6（1000℃*16h) | 1.1（1000℃*16h) | 0.8（1000℃*16h) | |||||
Main Products
Company Profile
Factory & Customer
Certifications
Package Transport
FAQ
Q1.How do you control your quality? |
for each production process, zjyt has a complete product quality control system. After production, all goods will be tested, and the relevant quality certificates and test reports will be provided to you by email. |
Q2.Are you a manufacturer or a trader? |
We are a real manufacturer. We can not only provide high-quality products, but also provide，The best price, pre-sales service and after-sales service. |
Q3.Can you provide free samples? |
Of course, there are free samples, but you need to bear the freight. |
Q4.What is the product lead time? |
It usually takes about 15-20 days after receiving the order. |
Q5.Can we visit your factory? |
Yes, of course, you are welcome to visit our factory and inspect our products on site.In addition, if you need, we can discuss more details of technical cooperation. |
Q6.What is the warranty period of your products? |
If there is any quality problem, our products have a warranty period of at least one year。 |
Q7.What is the minimum quantity of a trial order? |
There is no limit. We can provide the best suggestions and solutions according to your situation. |
Q8.Why choose us? |
Our R & D personnel have 20 years of technical experience, which can not only provide you with high Quality products, competitive prices, and we can provide good technical services. This can help you solve the problem. |
Q9.What standards do you have? |
Our products comply with ASTM, ASME, AMS, DIN, JIS and other standards. We can conduct third-party testing. |
