BW850/5 Horizontal Double Cylinder Reciprocating Double Action Piston Mud Water Pump
- Category: >>>
- Supplier: Ningbo Zhedong Geological Equipment Co. Ltd.Ningbo Ltd.
Share on (1600594625023):
Product Overview
Description
Product Description
BW850/5 Mud Pump is a horizontal double cylinder reciprocating double acting piston pump. Its structure is simple, compact, variable convenience, light weight, pressure, easy to operate. Used in the hole pressure to send rinse, and supporting 600-800 meters depth of the use of large diameter drill rig.
Technical Parameters
Type | Horizontal Double Cylinder Reciprocating Double Acting Piston Pump | ||||||
Stroke (mm) | 260 | ||||||
Cylinder Diameter (mm) | 66 | ||||||
Pump Speed (min-1) | 140 | 130 | 95 | ||||
Flow (L/min) | 850 | 600 | 350 | ||||
Pressure (MPa) | 5 | 6 | 8 | ||||
Power (KW) | 90 | ||||||
Shape Size (mm) (L×W×H) | 3018×1120×2050 | ||||||
Weight (kg) | 3100 | ||||||
