Новинка, горячая Распродажа, 4K NDI 1080P60FPS 12X 20X оптический зум, камера для видеоконференций, PTZ трансляция, прямая трансляция
- Category: Office Equipment >>>
- Supplier: World,Win,Technology,(Shenzhen),Co.,Ltd.
Share on:
Product Overview
Description
Tip:
1.→→Click here to inquiry←Get better discount price.
2.OEM/ODM are also welcome；
3.Excellent quality and better Price.
3.Excellent quality and better Price.
4. This appearance WIN-J86 series, we have 4K and HD1080P resolution for option,12X and 20X Optional Zoom, SDI or NDI version to suitable for your different place, Contact us for more details.
Products Description
New Hotsale 4K NDI 1080P60FPS 12X 20X Optical Zoom Video Conference Camera PTZ Broadcasting Live Streaming Camera
WIN-J86AK/AKN
WIN-J86 4K NDI PTZ Live Streaming Camera Selling Points:
1. WIN-J86AK is Ultra HD 4K 30FPS PTZ Camera compatible HD1080P60fps
2. Have 2 version, can choose NDI|HX2 protocol version which is low latency3. 4K PTZ Camera J86 have 20X or 12X Optical Zoom for optional
4. With Tally light, two green color light
5. Support POE, Power on ethernet
6. USB3.0 support H264, SDI and LAN port is good for live streaming,
7. Low noise and High SNR
8. Easy be control via IR remote and Joystick Controller
9. Have black color , white color also can be OEM
10. Wall mounting, desktop or ceiling mounting
Model No.: | ||||||
Zoom | ||||||
Wide Angle | 58.7° | 58.7° | 72.5° | 58.7° | 56° | 56° |
Interface | USB3.0, SDI, HDMI | USB3.0, SDI, HDMI | USB2.0, SDI, HDMI | USB2.0, SDI, HDMI | SDI, HDMI,USB3.0 | SDI, HDMI,USB3.0,LAN |
LAN, POE | LAN, POE | LAN | NDI(LAN), POE | LAN, POE | NDI, POE | |
RS232, RS422, RS485 | RS232, RS422, RS485 | RS232, RS422, RS485 | RS232, RS422, RS485 | RS232, RS422, RS485 | RS232, RS422, RS485 | |
Color | Black | Black or White | Black or White | Grey | Black | Black |
Details Images
Tally Light Indicator
WIN-J86AK 4K PTZ Live Streaming Camera is with super green color indicate Tally light, easy to see and easy operate.
NDI 4K Conference Camera WIN-J86 have 20X and 12X Zoom
NDI 4K PTZ Camera WIN-J86 series, have 12X and 20X optical zoom for choice, suitable for middle and large size room.
WIN-J86 Multi-interface
The interface of this 4K Video Conference Camera is with USB3.0, HD-MI, LAN, SDI video ports, RS232/422/485 control interface, NDI ports and POE support.You can choose USB3.0+HDMI output 4K image or LAN+HDMI output 4K 30FPS.
255 Presets Position
WODWIN 4K PTZ Conference Camera WIN-J86AK can be set 9 presets via IR Remote and set 255 Presets position via PTZ Joystick Controller.
Camera Control Connection Method
WODWIN WIN-J86AK IP POE SDI PTZ Camera can be control by many method, such as NDI or IP Joystick Controller, Ir Remote Controller, IP web browser, or Software such as Vmix, OBS..And the Connection Diagram as show in this picture.
WIN-J86AK 4K PTZ CAMERA COMPATIBLE WITH VARIOUS SOFTWARE
WIN-J86AK 4K Conference Camera, WIN-J86AKN, the NDI 4K PTZ Camera both are compatible with various Conference and Live Streaming Software in the market such as ZOOM, SKYPE, VIDYO, CISCO WEBEX, FACEBOOK, YOUTUBE, TWITTER, INSTRAGRAM, GOOGLE HANGOUTS and so on.
Installation of the NDI 4K PTZ Camera
WIN-J86AKN NDI 4K PTZ Live Streaming Camera can be install on the wall, ceiling, also by tripod and desktop.
Application of the NDI PTZ Camera
This WIN-J86AKN NDI PTZ 4K Live Streaming Camera can be used in many application such as Conference Room, Government, Concerts, Church, Tele-medicince and so on.
Product Paramenters
Product Name | 4K PTZ Live Streaming Camera | ||
Item No. | WIN-J86RK | WIN-J86AKN | |
Effective Pixels | 3.10 Megapixels | 3.50 Megapixels | |
Lens | 12X Optical Zoom | 20X Optical Zoom | |
Horizontal View Angle | 72.5°(W)~7.4°(T) | 58.7°(W)~3.2°(T) | |
Interface | HDM1, SDI, USB3.0, IP, POE | HDM1, SDI, USB3.0, IP, POE, NDI|HX2 | |
Pan | 355°(max.speed:80°/s) | ||
Tilt | -30°to 90°(max.speed:60°/s) | ||
Signal | PAL/NTSC | ||
Minimu Illumination | 0.1Lux | ||
Protocol | SONY VISCA、PELCO P/D | ||
Control Mode | RS-232C、RS-422/485 | ||
Dimension | (L)147 ×(W)147 ×(H)165mm | ||
Power | 12V DC(10.8～13.0V DC) | ||
Accessories | DC 12V power adapter, IR Remote, Operation manual, RS-232C Cable, HDM cable, USB Cable, Ceiling bracket | ||
Product packaging
Recommend Products
WIN-J86RS
SDI+HDMI+IP+USB3.0
HD1080P 12X/20X Zoom
WIN-J86AN
SDI+HDMI+IP+USB3.0+NDI
HD1080P 20X or 12X Zoom
WIN-91AF
USB3.0+HDMI+SDI+LAN
12X/20X Zoom
WIN-M49K
4K Voice Tracking Camera
USB3.0+HDMI+IP
12X Optical Zoom
WIN-J40RK
4K PTZ Camera
USB3.0+HDMI+IP
12X Optical Zoom
WIN-JC20
IP PTZ Camera Controller
RJ45,RS232,RS485
PVW 3-Inch Color Scren
Company Profile
WODWIN- China Supplier Factory of Audio and Video Conference Camera Solution
WODWIN is the leading brand of the Video Conference Solution, the professional provider of the conferencing system, we have our own factory of Video Conference Cameras, Conference Speaker, Joystick Controller and with rich supply chain in the related conferencing products such as Video Extender, POE switcher, Hub, Tripod and so on.
