D69 2058 6 in 1 HD LCD Multi Function Digital Display Voltage Current Power Frequency KWH Meter Multiple Colour Digital Panel Wa
- Category: >>>
- Supplier: Yueqing Junxiong Imp. & Exp. Co. Ltd.
Share on (1600598319862):
Product Overview
Description
Name | D69-2058 6 in 1 HD LCD Multi-Function Digital Display Voltage Current Power Frequency KWH Meter Multiple Colour Digital Panel Wattmeter |
Current range | 0-100A |
Voltage range | AC200V-AC450V |
Frequency | 45-65Hz |
P.F. | 0-1.0 |
Specification
1. Accuracy: 1% 2 words
2. Range:
AC voltage: AC 80.0-300.0V/200.0-450.0V(You should select the suitable type of
meter when your making order)
AC current: AC 0-99.99A, minimum resolution is 0.01A
AC current: AC 0-40.00A, minimum resolution is 0.01A
power frequency: 45.0Hz-65.0Hz
power factor : 0.00-1.00PF
active power: 0-45000W when the active power between 0 and 9999.9W, the display accuracy is 0.1W
Electric energy: 0-9 99999kwh,when the electric power between 0 and 999.99kwh, the
display accuracy is 0.01kwh, when between 10000.0-9999.9kwh, the display
accuracy is 0.1kwh,when between 10000.0 and 999999kwh, the display
accuray is 1kwh.
3.Speed: 2 times per second
4.Size: 79*43*48mm
5.Installation Size: 76*39mm
6.Auto-saving: when power off, the electric energy will be saved. The saved electric energy will
Be accumulated continue when the meter power-on next time.
1. Accuracy: 1% 2 words
2. Range:
AC voltage: AC 80.0-300.0V/200.0-450.0V(You should select the suitable type of
meter when your making order)
AC current: AC 0-99.99A, minimum resolution is 0.01A
AC current: AC 0-40.00A, minimum resolution is 0.01A
power frequency: 45.0Hz-65.0Hz
power factor : 0.00-1.00PF
active power: 0-45000W when the active power between 0 and 9999.9W, the display accuracy is 0.1W
Electric energy: 0-9 99999kwh,when the electric power between 0 and 999.99kwh, the
display accuracy is 0.01kwh, when between 10000.0-9999.9kwh, the display
accuracy is 0.1kwh,when between 10000.0 and 999999kwh, the display
accuray is 1kwh.
3.Speed: 2 times per second
4.Size: 79*43*48mm
5.Installation Size: 76*39mm
6.Auto-saving: when power off, the electric energy will be saved. The saved electric energy will
Be accumulated continue when the meter power-on next time.
1.How can we get quotations?
A:We will send quotations within 24 hours after we get your enquiry. Urgent need you can call us or send us messages via Skype/Whatsapp.
2.Can we get sample to check your quality?
A:All items sample are available.Special make products will take a few days.
3.Can you do the design for packing?
A:Yes. We have ad team can assist you design inner and outer box if need. Can also help you design catalog if required.
4.How long to ship the sample?
A:Samples will be shipped by TNT DHL UPS EMS to arrive you around 7 days.
5.What is your terms of delivery?
A:Normally we work on EXW FOB CIF.
A:We will send quotations within 24 hours after we get your enquiry. Urgent need you can call us or send us messages via Skype/Whatsapp.
2.Can we get sample to check your quality?
A:All items sample are available.Special make products will take a few days.
3.Can you do the design for packing?
A:Yes. We have ad team can assist you design inner and outer box if need. Can also help you design catalog if required.
4.How long to ship the sample?
A:Samples will be shipped by TNT DHL UPS EMS to arrive you around 7 days.
5.What is your terms of delivery?
A:Normally we work on EXW FOB CIF.
