LANBOO 16A 250V Stainless Steel/copper Plating/aluminum Oxide High Quality Aluminum Panel Waterproof Rocker Switch

LANBOO 16A 250V Stainless Steel/copper Plating/aluminum Oxide High Quality Aluminum Panel Waterproof Rocker Switch

Price:$3.40 - $3.80

Price in USD:Details

Quantity:

Product Description

Model Description
Model NO.	LB2822-rocker switch
Mounting diameter	28*22mm
Mounting thickness	≤3.5mm
Contact resistance	≤50MΩ
Dielectric Strength	3000VAC,50HZ,1min
Rated load	AC-15:110V/250V:20A DC-15:12V/24V/36V:20A
Electrical Life	AC250V/20A, DC36V/20A: 10,000 times; AC250V/8A, DC36V/8A: 40,000 times; AC250V/3A, DC36V/3A: 100,000 times
Mechanical Life	200,000 times
LED Rated Current	≤24V,≤20mA;>24V,≤10mA
Illuminated LED Color	Red,Green,Blue,Yellow,White

2822-1- (1).jpg 2822-1- (2).jpg 2822-1- (3).jpg 2822-1--(4).jpg 2822-1- (5).jpg 2822-1- (6).jpg 2822-1- (7).jpg

Packaging & Shipping
