380L Industrial dehumidifier three phase for USA market

Product Overview

Description

Model	HAID-380C	HAID-480C
Power Supply	3N 220V/60HZ	3N 220V/60HZ
Power Consumption	6800W	7400W
Rated Current	18A	25AS
Dehumidify Capacity (30℃,80%RH)	380L/Day	480L/Day (30℃,80%RH)
Water drainage	yes	yes
Condensate water pipe diameter	16mm	16mm
Fan type	Centrifugal Fan	Centrifugal Fan
Noise	≤68dB(A)	≤75dB(A)
Air Circulation (m³/h)	5000	6000
Compressor brand	Hitachi or GMCC	Hitachi or GMCC
Refrigerant /Charge	R410a/3.2Kg	R410a/3.6Kg
Hot gas working in low temperature	5-38℃	5-38℃
Control Type	Electircal	Mico computer
Humidity seting range	10-90%	10-90%
High Low pressure protection device	Yes	Yes
3 minutes delayed for protecting	Yes	Yes
Auto Defrost	Yes	Yes
Charging gas valve	Yes	Yes
Oil filter	Yes	Yes
Timing	1-24hours	1-24hours
Body Size(mm)	H185*L119*W45CM	H185*L119*W45CM
Package Size(mm)	190*131*60CM	195*131*60CM
Net Weight	220kg	220kg
Gross Weight	240kg	240kg
Loading Quantity(20`/40'/40'HQ)	17/36  pcs	17/36  pcs



Features:

1. LED display: the display will show current humidity,current temperature, timing on/off, water tank full alarm and machine alarm error codes.



2. Timer function: you can set the time to start the industrial dehumidifier when the machine is under standby status. You can set the time to stop this industrial dehumidifier when the machine is under running status. And you can set the timer ON and OFF together which will running and OFF the machine as cycle



3. 10%-90% Humidity setting range: industrial dehumidifier humidity setting range from 10%RH to 90%RH, the industrial dehumidifiers will work automatically when humidity arrived stop working when humidity higher than 5% start to working.



4. Using 0.32mm thick internally threaded copper pipe, high heat exchange efficiency



5. Electrical components adopt internationally famous brands such as ABB or Schneider or China Electric

6. Auto defrost: this industrial dehumidifier will automatically defrosting when temperature lower than 15C

7. Washable Air filter:  this commercial dehumidifier equipped nylon filter, the filter is washable.

8. Can add hot gas working in low temperature

9. Auto restart function.
