Product Overview
Description
Coriolis Feeder for weighing powder 24 Hours Technology Supporting
Product Description
Product Introduction
FB-CMF Coriolis Powdery Feeder System is mainly used in coal feeding for kiln head and kiln tail of cement plant and measurement for mixture of fly ash in cement grinding plant.
Product Photos
Product Features
1.The system adopts FB-DACS5000 control system,namely PLC+touch screen.
2.It is a set of system that can realize continuous feeding and weighing.
3.Reasonable structure, convenient maintenance and reliable operation.
4.Automatically measure system zero and calculate calibration factor.
5.Friendly touch screen operating interference makes the operation simple, and the control process and system statue can be displayed on-line.
6.Special parameter table is set to make the system operate in best conditions, and the centralized and local switching can be realized in screen.
7.The system has the display function of shift accumulation, daily accumulation and total accumulation.
8.Torque detection adopts customized dynamic torque sensor.
9.The system has the function of self-diagnosis and can be connected to DSC system.
10.The system adopts integrated framework, vertically fix dynamic torque sensor, assemble precision, stable running.
Main parameters
Weighing Accuracy | ±0.5% |
Authenticate | ISO9001:2008 quality system |
Working Voltage | 380V AC 50-60Hz |
Ambient Temperature | -30-50°C |
On humidity | 30-85% RH |
Material | Stainless steel |
Weighing Range | 1-200t/h |
Controller | PLC control box |
Specifications:
NO. | Type | Weighing Range( m³/h ) |
1 | FB-CMF06 | 1.2~6 |
2 | FB-CMF09 | 2~9 |
3 | FB-CMF15 | 3~15 |
4 | FB-CMF25 | 5~25 |
5 | FB-CMF40 | 8~40 |
6 | FB-CMF60 | 12~60 |
7 | FB-CMF90 | 18~90 |
8 | FB-CMF135 | 27~135 |
9 | FB-CMF200 | 40~200 |
10 | FB-CMF300 | 60~300 |
11 | FB-CMF450 | 90~450 |
Patents
NO. | Name | Patent Number |
1 | Coriolis powdery feeder system | EL200420010484.X |
2 | Coriolis powdery flow meter | EL200420010485.4 |
3 | Coriolis powdery flow meter Measuring plate | EL2009203178674 |
4 | Coriolis powdery flow meter | EL2009203179037 |
5 | A Coriolis weighing scale | EL2011200873048 |
Packaging & Shipping
Packaging
1.Outside: Standard export wooden case ( as your request)
2.Inner: stretch film
Shipment
within 30 days after the payment
Our Services
Our services
1) Provide professional and detail program according to customer's requirement.
2) Engineers available to service machinery overseas.
3) Providing 24 hours technology supporting.
4) Supplying free training for installation, commissioning and maintenance.
5) Changing new for you in the guaranteed time.
Company Information
Founded in 1997, Fengbo Automation is involved in providing precise dynamic measurement instrument to our customers in domestic and abroad.
Certificates
Exhibition
Our news
FAQ
Customer's Notice
1.Each equipment is not standard.
2.Therefore, we need you to send us specific inquiry.
3.Then we can quote price and detailed information according to your specific technical dates and requirements.
Parameter includes
1 What' s the material you want to weigh or convey?
2 What are the physical characteristics of the material?
Such as the size, temperature, density, moisture content, etc.
3 What about the normal feed rate? Mini. And max. Feed rate?
Welcome your questions and messages all the time and we will answer your any questions on time.
