Product Overview

Description

Tektronix FCA3120

20 GHz, 3-Ch Frequency Counter/Analyzer





Product Features:

• 20 GHz Timer


• 3 Input Channels


• 50 ps Single-shot Time Resolution


• 12 Digit/s Frequency Resolution


• 0.001° Phase Resolution


• 3 mV or better Voltage Resolution


• Optional 5×10–8 High-stability Oven Time Base


• 250k Sample/s Data Transfer Rate to Internal Memory(Up to 3.75M samples stored)


• Up to 15k Sample/s Data Transfer Rate over USB/GPIB Bus(Block mode)


• Up to 650 Individually Triggered Measurements/s


• Automated Measurements: Frequency, Period, Ratio, Time Interval, Time Interval Error, Pulse Width, Rise/Fall


• Time, Phase Angle, Duty Cycle, Maximum Voltage, Minimum Voltage, Peak-to-Peak Voltage


• Multi-parameter Display


• Trend Plot Mode


• Measurement Statistics Mode


• Histogram Mode


• Allan Deviation


• Zero Dead-time Frequency/Period Measurements


• Programmable Pulse Output from 0.5 Hz to 50 MHz


• Optional Rear-panel Inputs


• USB Device and GPIB Ports on Rear Panel for Quick PC Connectivity


• GPIB Interface Supports Full SCPI-compatible Programmability and offers an Emulation Mode for Plug-and-Play Replacement in Existing ATE Systems


• External Arming Input


• 10 MHz Reference Oscillator Output


• Includes National Instrument’s LabVIEW SignalExpress TE Limited Edition Software for Connecting Your Bench


• Optional TimeView Software Available for Modulation Domain Analysis





Our service



One-stop service from manufacture to shipping.

1. Your inquiry related to our products or prices will be replied in 24hours.

2. Well-trained and experienced staffs to answer all your enquires influent English.

3. Distributor ship is offered for your unique desigh and some our current models.

4. Protection of your sales area, ideas of design and all your private information.



Trade terms



1. Payment: T/T,Paypal, Western Union, MoneyGram

2. Production lead time:2-4 week

3. Sample can be delivered: 1 week

4. Shipping freight are quoted under your requests

5. Shipping port: Shenzhen Mainland China, Hong Kong.

6. Discounts are offered based on other quantities
