Price:$35,000.00 - $42,999.00

Quantity:


Product Overview

Description









The main technical parameters
VMC855
X axis
800mm
Y axis
550mm
Z axis
550mm
Spindle end face to workbench
100-650mm
Spindle center to column guide
571mm
T slot
5×18×100mm
Spindle taper
BT40
Max. spindle speed
8000 （optional:10000/12000）r/min
Cutting feed
10m/min
Main motor connection
belt （optional:direct）
Main motor power
7.5KW
X/Y/Z axis servo motor torque
15/15/23N·m
X/Y/Z motor connection
direct
X/Y/Z guide rail form
3 axis linear guide rail
Max.table load
500KG
Automatic tools changer
24 arm type (optional:20 carousel type)
Max.tool weight
8KG
Max. tool length
300MM
Position accuracy
±0.005/300MM
Repeat positioning accuracy
±0.003MM
X/Y/Z axis rapid traverse
18(optional :36)M/MIN
weight
about 5200KG
Dimensions
about 2800x2100x2300














Product packaging




FAQ


1.who are we?
We are based in Shandong, China, start from 2010,sell to Domestic Market(75.00%),North America(5.00%),Africa(5.00%),Southeast Asia(4.00%),Southern Europe(4.00%),Eastern Asia(3.00%),Eastern Europe(2.00%),South Asia(2.00%),Mid East(0.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
CNC Milling Machine,CNC Sawing Machine,Milling Machine,Drilling Machine,Lathe
4. why should you buy from us not from other suppliers?
Shandong GOLD CNC Machine Tool Co., Ltd. established in 2010, is a professional manufacturer engaged in the research, development, production, sale and service of CNC milling machine, CNC sawing machine, milling machine, drilling machine, lathe.
5.what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,D/P D/A,PayPal;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
