Custom Electronic FR4 Lead Free Double Sided 2 Layers 94v0 PCB Printed Circuit Board mosquito racket pcba assembly
- Category: Double-sided PCB >>>
- Supplier: Shenzhen Thriver Digital Tech Co. Ltd.
Share on (1600599860093):
Product Overview
Description
We are OEM PCB and PCBA manufacturer since 2012 ,we can provide PCBA One stop turnkey solution ,
including PCB fabrication,SMT and assembly PCBA,Function testing and other value-added service.
Shenzhen Thriver Digital Technology Co.,Ltd focas on PCB&PCBA Manufacturer for over 10 years.
we provide one stop turnkey service of PCBA,including PCB laylout,PCB maufacture,assembly,Test service and also offer the components purchasing.
We have exported our products to many countries for over 10 years. The constant quality and customers' satisfaction have got us a good reputation of a dependable PCB Assembly supplier.
What we can do?
1.We can make and design all kinds of PCBA board according to your demand,
Such as:
Power supply PCBA Board ,
Power Amplifier PCBA Board,
BT-Speaker PCBA Board,
Industrial control board,
custom inverter PCBA board,
PCBA protection board for 18650 battery.
Temperature control board PCBA,etc.(All PCBA boards welcome Support customized )
2.Our engineer teams have about 10 years PCBA boards R&D experience,all of their design are widely used many famous brand Products.
3.All the customized PCBA boards order all following by our single engineer,from design to shipping goods.
We can do Different Types of PCB
1.Single Sided PCB or Single Layer PCB
2.Double Sided PCB or Double Layer PCB
6.Rigid-Flex PCB or Rigid- Flexible PCB
About our services:
1.PCB Layout Design
2.Sample & Prototype Building
3.PCB Assembly
4.Electronic Components Sourcing Service
5.PCB clone: reverse engineering, with all compoentns compeleted.
Multilayer Electronics PCB Components Assembly
Application Field
Printed circuit boards And PCB Assembly are mainly used for many communication industry, medical equipments, consumer electronics , automotive electronics ,
audio and video, optoelectronics, robotics, hydroelectric power, aerospace, education, power supply, printer ,Auto Industry ,Smart Home.etc.
SMT Turnkey Multi-layer Double Sided pcb design and assembly
PCB testing service.
1. Manual visual inspection of PCB board
2. PCB board online test
3. PCB board function test
4. AOI (Automatic optical inspection)
5. Automatic X-ray inspection
6. Laser detection system
7. Size detection
Information needed of PCB/PCBA Assembly quote:
1.DO PCB : Please offer PCB Gerber file to us.
2.DO PCBA: Please offer PCB Gerber file and Bom list (list of components).
3.COPY PCB/PCBA: Please offer us the details information of PCB/PCBA, if can send us the sample ,that’s best.
If you need any pcb or pcba service,welcome to enquiry from us!
Hope we can cooperate and work together! we are professional and we will be your reliable PCB Board &PCB assembly service supplier.
PCB Capacities and Technical Specification
| Name | PCB circuit board |
Layer | 1,2,4,6,upto 24 layers |
Material | FR- 4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc |
PCB type | Rigid,flexible,rigid- flexible |
Shape | Customozed shape: Rectangular,round,slots,cutouts,complex,irregular,etc. |
Max PCB dimensions | 500mm*500mm |
Thickness | 0.2~4.0mm, Flex 0.01~0.25'' |
Thickness tolerance | ± 10% |
Copper thickness | 0.5-4 oz |
Copper thickness tolerance | ± 0.25oz |
Surface finish | HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc |
Solder mask | Green, red,white,yellow,blue,black, etc |
Silk screen | White,yellow,black |
Silk screen min line width | 0.006'' or 0.15mm |
Min drill hole diameter | 0.01'',0.25mm.or 10 mil |
Min trace/gap | 0.075mm or 3mil |
PCB cutting | Shear,V-score,tab-routed (according to customer demand) |
PCBA Capabilities
Turnkey PCBA | PCB+components sourcing +assembly+package |
Assembly details | SMT and Thru- hole, ISO SMT and DIP lines |
Testing on products | Flying Probe Test, X-ray Inspection, AOI Test, Functional test |
Quantity | Accept samples order. Prototype, small order, mass order, all accept. |
Files needed | PCB: Gerber files |
Components:Bom list(list of components) | |
Assembly: Pick-N- Place file | |
PCB Panel Size | Min size: 0.25*0.25 inches(6*6mm) |
Max size: 500*500mm | |
PCB Solder Type | Water Soluble Solder Paste, RoHS lead free |
Components details | Passive Down to 0201 size |
BGA and VFBGA | |
Leadless Chip Carriers/CSP | |
Double- sided SMT Assembly | |
Fine Pitch to 0.8mils | |
BGA Repair and Reball | |
Part Removal and Replacement | |
PCB assembly | Drilling-----Exposure----- Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT----- Wave Soldering-----Assembling-----ICT-----Function Testing----- Temperature & Humidity Testing
|
Q:What is needed for PCB/PCBA quotation?
A: For Bare PCB project quotation:
Please provide Quantity, Gerber file and specification include PCB material,Size, surface finish treatment, copper thickness,
board thickness, soldermask color and silkscreen color ,HASL or HASL-LF and other special specs.
For PCBA project quotation:
Please provide above information as well, and BOM list.If you need turnkey service include programming and functional testing etc, kindly contact us for more details.
Q:Are my design files secure when I send them to you?
A:We warranty that Your files are never shared nor will any third parties have access to your design files. We can accept sign an NDA(Non-disclosure agreement) before sending files.
Q.May I have a sample for testing ?
A:We can supply the sample if we have ready parts in stock,we also can accoring to custom demand to design the PCBA samples to test first before big order .
Q:Are you factory or Trading company?
A: We are a factory with PCB maufacture and SMT assembly factory in China .
Q:Do you have an minimum order quantity?
A:We accept sample order with as low as a quantity of 1 (piece or panel) before bigger order.
Q. How about your delivery time?
A: Generally, goods would be shipped in 7-10 working days after payment received, finally depends on order quantities.
Q:what's the Payment way?
A:TT ,Western Union, Alibaba online payment
Q. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q: Can I customized for product?
A: Yes, we support OEM ODM
Q.What is your warranty ?
A : Within 60 days after package have been received .
Q.What is your terms of payment ?
A : Full Payment before send goods out.
Q: How to send the goods?
A: Small QTY: ship by express included in DHL, FedEx UPS and TNT. Door to door.
Large QTY: Ship by sea, or by air.
Q: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from.
Q. Do you accept process materials supplied by clients?
A: Yes, we can provide component source, and we also accept components from client.
