1~10 tons small virgin coconut oil refinery uses coconut oil refining machine to make edible oils
- Category: >>>
- Supplier: Dalian Reyes Import & Export Co. Ltd.
Share on (1600600600876):
Product Overview
Description
1~10 tons small virgin coconut oil refinery uses coconut oil refining machine to make edible oils
1~10 tons small virgin coconut oil refinery uses coconut oil refining machine to make edible oils is used for cleaning crude oil, when you produce the oil by the oil press, the oil can not eating directly, you must cleaning the oil, include degumming and deacidification, decolor, deodorization three sections, oil after refined can be selled or ate directly.
Edible oil refining machine Features
1) Simple structure in linear type, and easy in installation and maintenance.
2) Adopting advanced China famous brand components in electric parts and operation parts.
3) Full automatic and continuous working
4) Running in a high automation and intelligentization with no pollution.
5) Environmental friendly, low noise and power consumption
Small scale edible oil refining machine coconut crude oil refinery machine features :
1) Simple structure in linear type, and easy in installation and maintenance.
2) Adopting advanced China famous brand components in electric parts and operation parts.
3) Full automatic and continuous working
4) Running in a high automation and intelligentization with no pollution.
5) Environmental friendly, low noise and power consumption
PRODUCT SPECIFICATIONS
1~10 tons small virgin coconut oil refinery uses coconut oil refining machine to make edible oils
Model | RES-500A | RES-750-B | RES-750-C |
Air pump Power | 1.1Kw | 1.1Kw | 1.1Kw |
Self-priming pump | 1*0.37Kw | 2*0.75Kw | 3*0.75Kw |
Heating tube | 3*2Kw | 6*3Kw | 9*3Kw |
| Capacity | 150-170KG/H | 300 KG/H | 500 KG/H |
Oversize | 1500*580*1350mm | 3120*830*1550mm | 3900*830*1550mm |
Weight | 140kg | 280kg | 350kg |
Mixing tank | 1 | 2 | 3 |
Voltage | 380V/50Hz | 380V/50Hz | 380V/50Hz |
Detail
1~10 tons small virgin coconut oil refinery uses coconut oil refining machine to make edible oils
1~10 tons small virgin coconut oil refinery uses coconut oil refining machine to make edible oils
Working Principle
The small edible oil refiner uses the principle of different density and incompatible light, heavy liquid and solid phasesin the mixed liquid, and different settling speeds in gravity to achieve the purpose of separating and stratifying or allowingsolid particles in the liquid to settle ; After separation, after ore fine filtration, adsorption, decolorization, etc., the oil becomes clear and fragrant.
Crude oil - degumming (washing) - deacidification (alkali refining) - decolorization (white clay adsorption) - dehydration (heat drying) - refined oil
The small edible oil refiner uses the principle of different density and incompatible light, heavy liquid and solid phasesin the mixed liquid, and different settling speeds in gravity to achieve the purpose of separating and stratifying or allowingsolid particles in the liquid to settle ; After separation, after ore fine filtration, adsorption, decolorization, etc., the oil becomes clear and fragrant.
Crude oil - degumming (washing) - deacidification (alkali refining) - decolorization (white clay adsorption) - dehydration (heat drying) - refined oil
1~10 tons small virgin coconut oil refinery uses coconut oil refining machine to make edible oils
Product application
The oil refinery is mainly used in the oil refining process of large oil plants, with high refining rate and continuous process, and can refine different grades of oils and fats. Including all kinds of vegetable oils: soybean, peanut, cottonseed, rapeseed, jade, etc. are suitable for all oil-containing plants.
Product application
The oil refinery is mainly used in the oil refining process of large oil plants, with high refining rate and continuous process, and can refine different grades of oils and fats. Including all kinds of vegetable oils: soybean, peanut, cottonseed, rapeseed, jade, etc. are suitable for all oil-containing plants.
Different models of machines have different capacities, sizes and prices. Choose the appropriate model according to your needs.For details, please consult customer service.
Company Profile
Dalian Reyes Machinery Co.Ltd . is a professional manufacture and supplier of centrifuge ,filling machine,oil press machine and many packing machine .We have a well-experienced team to manufacture separator machine ,packing machine ,mixing machine ,dry ice production ,all kinds of dryers and so on .With rich experience in separator equipment and a number of professional engineers .
In past years , we have made a great achievements due to our good credit and service . We have established long-term business relationship with many customers .
In Reyes , you can get your desired products with best price and high quality . We welcome your requires ,and we will do our best to help you to choose products .
