Performance Paramete
Infront Chinese loader skid steer YF380 best quality for sale
YF380 skid steer loader
Item
|
Item
|
Engin
|
Rated power(KW)
|
15.4KW(21HP)
|
|
Rated speed(rpm)
|
3300
|
Noise (Db)
|
95
|
Hydraulic system
|
Hydraulic pressure(Mpa)
|
17
|
|
Cycle time(s)
|
Raise
|
Dump
|
lower
|
|
|
4.27
|
1.34
|
3.31
|
Technical Parameter
|
Operating Load
|
200 Kg
|
441lb
|
|
Bucket Capacity
|
0.15 m3
|
5.33(ft 3)
|
|
Max Lifting Force
|
375 Kg
|
827lb
|
|
Travel Speed
|
0-5.5Km/h
|
0-3.4mile/h
|
|
Operating Weight
|
890 Kg
|
1958lb(With Chevron Engineering Tyre )
|
Tires
|
18*6.5-8
|
Item
|
With Chevron Engineering Tyre
|
Max working height H1
|
2143mm
|
84.37inch
|
Max dump height H2
|
1488mm
|
58.58inch
|
Total Height H
|
1233mm
|
48.54inch
|
Max pin height
|
1884mm
|
74.17inch
|
The length of the foot plate
|
678 mm
|
26.7inch(foot plate level)
|
Total length with bucket L ( mm)
|
2206mm
|
86.9inch
|
Highest point dump distance L1(mm)
|
348mm
|
13.7inch
|
Length without bucket L2(mm)
|
1752mm
|
69inch
|
Bucket width B(mm)
|
980mm
|
38.6inch
|
Total width B1(mm)
|
1160mm
|
45.67nch
|
Wheel base
|
940mm
|
37inch
|
Ground clearance(mm)
|
118mm
|
4.65inch
|
Turning radius R(mm)
|
1307 mm
|
51.5inch
|
Bucket dumping angle α(°)
|
30
|
|
Rollback of bucket on ground β(°)
|
25
|
|
Departure angle(°)
|
11(foot plate level)
|
Technical Features
A mini skid steer loader serves several purposes, with a quick hitch system,the small skid steer loader can change various attachments for more functions quickly and eaily. Attachments: backhoe, digger, sweeper, dump bucket, tiller, lawn mower, angle blade, breaker,4 in 1 bucket, snow blower,leveler,mixer, lawn aerator,trench filler, trencher,grapple,,auger,stonr bucket, auger levers,standard bucket,trailer system, and so on.
Our Services
1.Warranty
YingFang grants our clients a twelve-month-period or 2000-hours warranty for any truck purchased from us. During the warranty period, in case the defect of material or workmanship has occurred with spare in normal operation. the defective part will be repaired or replaced free of charge, at our discretion.
2.Spare Parts
YingFang is dedicated to provide our clients with genuine spare parts with the highest quality, exact fitness and appropriate function. With our global distributor network, you are guaranteed with fast deliveries and services, wherever you are. Please submit your spare parts request to us, and list products name, model, equipment serial number, description of required parts. We guarantee that your request will be handled quickly and appropriately.
3.Installation & Maintenance
YingFang is able to provide you with the overall installation of complicated construction machinery allowing you to start the normal operation of trucks immediately. After installation we will make inspection of the whole truck, operate equipment, and provide you with testing data reports of installation and operation.
4.Technical Advice
YingFang can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific truck. With our technical advices, your truck service life can be significantly prolonged and sustained with high capacity.
FAQ
1,How long will take to delivery the goods after placing an order?
It will take about 7days after getting the deposit if we have machine in stock. Some customized goods will need about 30days to delivery.
2,If our machines have any problems, When will your side can reply to us?
We will solve your problems immediately once get your message. Usually it will take 1~2hours to give you the solution or explanation.
3,What kind of good policy your can supply if we want to be your distributor?
Special discount and protection of sales area can be provided to your distributor.
4,Which incoterms 2010 terms can we work?
We are a professional and sophisticated international player, can handle all Incoterms 2010 terms, and we normally work on FOB,CFR,CIF,CIP,DAP Etc.
Please kindly provide us the following information before you send us email
1.what rated load you need?
2.do you need air conditioner?
3.you need fob or cif price? which port?
