Good quality Truck Axle for Low-bed series Type
US $399.00-$610.00
High Quality Semi Trailer Axle Parts Standard Size 13t/14t/16t/18t Axle Trailer Truck Used Customized CN;SHN Wooden Pallets 1pcs
- Category: Trailer Parts & Accessories >>>
- Supplier: Liangshan,Zhongxing,Machinery,Manufacturing,Co.,Ltd.
Share on:
Product Overview
Description
Specification
Axle beam: | 150*150mm*12mm |
Use | Trailer Parts |
Parts | Trailer Axles |
OE NO. | Inboard German type axle |
Max Payload | 55ton |
Size | Standard Size |
Place of Origin | China ,Shandong |
Track | 1840 |
Brand Name | ZONXIN |
Product Name | Hot Sale American Axle Semi Trailer Use Parts |
Material | Steel |
Keyword | Trailer Axle |
Surface | Color Painted |
Finish | Painting |
Weight | 375kg |
Color | Customer Demands |
Item | Wheel Trailer axle |
Usage | Trailer axle Casting Parts |
Package | Standard Package |
Product Description
Hot Sale German Axle Semi Trailer Use Parts
Product Description:
1. Products Name: Trailer Axle Parts Standard Size 13T Axle
2. Axle Track: 1840mm
3.Axle Beam: Square 150mm
4. Product type:American ,Germany and Japanese type
5.Max.capacity you can choose:12T,13T,14T,15T,16T
6.Stud:10*M20*1.5
7.Material: Steel
8.Products Capacity Available: 13T/14T/16T/18T/20T
2. Axle Track: 1840mm
3.Axle Beam: Square 150mm
4. Product type:American ,Germany and Japanese type
5.Max.capacity you can choose:12T,13T,14T,15T,16T
6.Stud:10*M20*1.5
7.Material: Steel
8.Products Capacity Available: 13T/14T/16T/18T/20T
Modle | Capacity | TR | Axle tube | Centre distance of brake chamber GM |
ZX/12T | 12000 | 1840 | 150 | 390 |
ZX/14T | 14000 | 1840 | 150 | 342 |
ZX/16T | 16000 | 1840 | 150 | 357 |
Noted:
1. TRACK can be customerized according to our customer
1. TRACK can be customerized according to our customer
2. CAM shaft can also be customerized according to our customer
3. According to customer requirement to assemble ABS
Other related products:
Quality advantage：
2. The heat treatment performance of shaft tube is stable, and the hardness value is HRC24 ~ 30
3. Advanced binding equipment increases the position thickness of the shaft tube bearing (26-29mm), which is 2-3mm higher than the peer, which is in the leading position in China.
Special new extrusion process is better
1. The key accessories adopt high-end configuration in the same industry
2. Perfect detection means -- comprehensive test platform for vehicle and axle performance
3. TS16949 quality system certification, comprehensive implementation of "5S" lean management, ERP information management.
Packing & Delivery
wooden pallets or wooden box ,as customers' request
