High Pressure Resistance Long Lifetime Swing Rod Diaphragm Valve Diaphragm Type Solenoid Valve
- Category: >>>
- Supplier: Shenzhen Keyto Fluid Control Co. Ltd.
Share on (1600610021141):
Product Overview
Description
Product Paramenters
Valve series | 1021 |
Structure | Direct-acting diaphragm, 2 way NC |
No.of ports | 2（specified inlet and outlet） |
Tube size | Suitable for 1.8-2.4mm inner diameter soft tube (shore hardness is about 55-75 degree) |
Body material | PVDF |
Diaphragm material | EPDM |
Voltage | 12V/24V |
Orifice diameter | 2mm |
Flow rate | 8.5g/s(25℃，50KPa ，H2O） |
Power consumption | 4.2W |
Withstand pressure | -70KPa~0.3MPa |
Products Description
Main Products
Company Profile
Certification & Exhibition
Production Process
Packaging & Shipping
FAQ
1.How can I customize my products?
Attach your drawings with details(Suface treatment,material,quantity and special requirements etc).
2.How long i can get the quaotation?
We will offer the quotation within 48 hours(Considering the time difference).
3.Are there any other requirements for the order?
OEM&ODM are welcomed.
4.Can I get a sample for testing?
We will offer free or charged samples depends on the products.
5.How long will you produce the parts?
Normally three weeks
6.What's your payment terms?
T/T
7.How about the transportation?
By sea or by air
Attach your drawings with details(Suface treatment,material,quantity and special requirements etc).
2.How long i can get the quaotation?
We will offer the quotation within 48 hours(Considering the time difference).
3.Are there any other requirements for the order?
OEM&ODM are welcomed.
4.Can I get a sample for testing?
We will offer free or charged samples depends on the products.
5.How long will you produce the parts?
Normally three weeks
6.What's your payment terms?
T/T
7.How about the transportation?
By sea or by air
