SRNE MPPT pv inverter 24V 48V 3000/5000/8000/10000 watt 3KW 5Kw 10kw 20kw 30kw pure sine wave hybrid solar inverter
- Category: >>>
- Supplier: Srne Solar Co. Ltd.
Share on (1600611106993):
Product Overview
Description
Products Description
Specification
Model | ASF4880U200-H | ASF48100U200-H | ||
INVERTER OUTPUT | ||||
Rated Output Power | 8,000W | 10,000W | ||
Max.Peak Power | 16,000W | 20,000W | ||
Rated Output Voltage | 120/240Vac（L1/L2/N/PE split phase） | |||
Load Capacity of Motors | 5HP | 6HP | ||
Rated AC Frequency | 50/60Hz | |||
Waveform | Pure Sine Wave | |||
Switch Time | 10ms（typical） | |||
BATTERY | ||||
Battery Type | Li-ion / Lead-Acid / User Defined | |||
Rated Battery Voltage | 48Vdc | |||
Voltage Range | 40-60Vdc | |||
Max.MPPT Charging Current | 200A | |||
Max.Mains/Generator Charging Current | 100A | 120A | ||
Max.Hybrid Charging Current | 180A | 200A | ||
PV INPUT | ||||
Num. of MPP Trackers | 2 | |||
Max.PV array power | 11,000W | |||
Max.input current | 22/22A | |||
Max.Voltage of Open Circuit | 500Vdc | |||
MPPT Voltage Range | 125-425Vdc | |||
EFFICIENCY | ||||
MPPT Tracking Efficiency | 99.9% | |||
Max. Battery Inverter Efficiency | 92% | |||
GENERAL | ||||
Dimensions | 620*435*130mm（2*1.4*0.4ft） | |||
Weight | 20kg（44lb） | 21kg（46.3lb） | ||
Protection Degree | IP20，Indoor Only | |||
Operating Temperature Range | -15~55℃,>45℃ derated （5~131℉，>113℉ derated） | |||
Cooling Method | Internal Fan | |||
Warranty | 2 Years | |||
CERTIFICATION | ||||
Safety | IEC62109-1, IEC62109-2,UL1741 | |||
EMC | EN61000-6-1, EN61000-6-3, FCC 15 class B | |||
RoHS | Yes | |||
Details Images
Certifications
Our Advantages
Company Profile
Packaging & Shipping
FAQ
Q1.What kind of certificates you have for your inverters?
A1:CE(IEC/EN62109-1,-2),ROHS2.0,cETL 2021
Q2.Are u a manufacturer or trading company?
A2:We are a state-level high-tech enterprise that integrates pluralism,R&D and manufacturing solar charge controller ,solar inverter charger
Q3.Can I buy one sample for testing?
A3:Sure,we have a 10 years experience R&D team and in timely after sale service,can help you fix any technical problem or confusion.
Q4.How is the delivery?
A4:Sample:1-2 working days
Order:within 7 working days depending on the order quantities
OEM order:15-20 working days after confirming the sample
Q5.How is your customers service?
A5:All solar product will be tested strictly one by one before leaving factory.And the defective rate is below 0.1% we do try our best to provide a good customer service.
A1:CE(IEC/EN62109-1,-2),ROHS2.0,cETL 2021
Q2.Are u a manufacturer or trading company?
A2:We are a state-level high-tech enterprise that integrates pluralism,R&D and manufacturing solar charge controller ,solar inverter charger
Q3.Can I buy one sample for testing?
A3:Sure,we have a 10 years experience R&D team and in timely after sale service,can help you fix any technical problem or confusion.
Q4.How is the delivery?
A4:Sample:1-2 working days
Order:within 7 working days depending on the order quantities
OEM order:15-20 working days after confirming the sample
Q5.How is your customers service?
A5:All solar product will be tested strictly one by one before leaving factory.And the defective rate is below 0.1% we do try our best to provide a good customer service.
