Innova UV Aging Climatic Environmental Test Chamber
Innova UV Aging test chamber can do two kinds of testing: aging and anti-yellowing.
It is used in many industries, such as: paint, inks, resin, plastics, printing and packaging, adhesives, auto and motorcycle industry, cosmetics, electronic,electroplating, medicine,etc.
Innova UV Aging test chamber designing Standard: IEC61215, ASTM D4329, D499, D4587, D5208, G154, G53; ISO 4892-3, ISO 11507; EN 534; prEN 1062-4, BS 2782; JIS D0205; SAE J2020, ect.
It is used in many industries, such as: paint, inks, resin, plastics, printing and packaging, adhesives, auto and motorcycle industry, cosmetics, electronic,electroplating, medicine,etc.
Innova UV Aging test chamber designing Standard: IEC61215, ASTM D4329, D499, D4587, D5208, G154, G53; ISO 4892-3, ISO 11507; EN 534; prEN 1062-4, BS 2782; JIS D0205; SAE J2020, ect.
Main Features:
1. UV aging test machine can do two kinds of testing: aging and anti-yellowing.
2. Aging: the machine can promote the increase of sulfur rubber deterioration, to calculate the change rate of tensile and elongation before and after heat. It’s generally thought that test for one day at 70°C, in theory as exposed to the atmosphere for 6 months.
3. Anti-yellowing: the machine stimulate the atmosphere environment, driven by the sun ultraviolet radiation. It’s generally thought that the appearance change at 50°C for 9 hours, in theory as exposed to atmosphere for 6 months.
2. Aging: the machine can promote the increase of sulfur rubber deterioration, to calculate the change rate of tensile and elongation before and after heat. It’s generally thought that test for one day at 70°C, in theory as exposed to the atmosphere for 6 months.
3. Anti-yellowing: the machine stimulate the atmosphere environment, driven by the sun ultraviolet radiation. It’s generally thought that the appearance change at 50°C for 9 hours, in theory as exposed to atmosphere for 6 months.
Products Technical Parameters
Model | INO-UVA-115 | INO-UVA-263 | |
Inner size: W*H*D(mm) | 1170*450*500 | 24pcs for each at 75mm*280mm, 48pcs in total | |
External size: W*H*D(mm) | 1350×1580×650 appr. | 1300×1560×600 appr. | |
Temperature range | RT~70°C | ||
Temperature fluctuation | ±0.5°C | ||
Temperature uniformity | ±2°C | ||
Humidity range | ≥90%RH | ||
Ultraviolet light | UV-A: 315-400nm; UV-B: 280-315nm (8pcs, 1600h lifetime); 8 pieces of Atlas Lamp, length: 120cm | ||
Controller | 7’’ touch screen Programmable controller | ||
Test cycle setting | Illumination, condensation and water spray test cycle is programmable | ||
Irradiance | ≤1.0W/m2 | ||
Materials | Inner material: 304#SUS; External material: Quality painted shell or 304#SUS | ||
Power supply source | AC220V 50/60Hz, 1 phase | ||
Related Products
Customer & Markets
>>Contact us to know more infos about your market
Get To Know Innova
Innova Bio-Meditech is one of the professional global providers of laboratory and medical devices. Firmly committed to our mission of “sharing innovative bio-meditech solutions with the world”, we are dedicated to innovation in the fields of Biology Project, Life Science, Pharmacy Industry and Medical Treatment.Products like bioreactor, glassware washer, freeze dryer, shaking incubator, anaerobic incubator, climate chamber, lab freezer, pharmacy refrigerator, vacuum autoclave, laboratory water purification system, etc for the life science and medical healthcare. All of these Innova products meet CE or ETL quality. Innova Bio-Meditech possesses a sound distribution and service network with business partners in North America and Latin America, Europe, Africa and Asia-Pacific etc. We have built up a well established R&D, manufacture network with 3 centers in Beijing, Qingdao, and Shanghai.
Inspired by the needs of our customers, we adopt advanced technologies and transform them into accessible innovation. This means constant effort and research, in order to more fully understand the developments of the market, produce constantly upgraded product ranges by adding new products year after year.
Inspired by the needs of our customers, we adopt advanced technologies and transform them into accessible innovation. This means constant effort and research, in order to more fully understand the developments of the market, produce constantly upgraded product ranges by adding new products year after year.
Recommend Popular Products
FAQ
Questions you may concern | Answers we would share |
What is the temperature range? | temperature: RT~70°C |
What is the Humidity range? | Humidity range: ≥90%RH |
Can it be customized size according to my requirements? | No problem, but custom products require you to provide the necessary information. |
How will you help us in the installation? | We offer online FAT and guidance of installation, after-sales training, in site installation with additional expense |
Do you have installation cases abroad? | Of course we do. We have installed bases in many places around the world and will share customer cases. Need to know your local installation case information, please feel free to contact us |
