Product Overview
Description
KEHONG Blue purple FEP Heat Shrink Tube high temperature medical grade colorful and clear FEP tube
Model: FEPST
Application
FEPST Heat shrinkable tubing is made of FEP, with excellent 200℃ high-temperature performance, chemical resistance, high insulation and mechanical properties, FEP have outstanding abration resistance and clarity features, designed to provide insulation and mechanical protection in several chemical and thermal environments, widely used in electronic, aerospace, military and communication fields.
Features
1. Shrink ratio 1.25:1
2. Excellent Clarity
3. High flame resistance
4. High temperature resistant to 200℃
5. Superior physical and chemical properties
6. RoHS and RECH compliant
7. Continuous Operating Temperature: -65℃to 200℃
8. Minimum fully recovery temperature: 210℃
9. Comply with SAE AMS-DTL-23053/11
Product Size:
| SIZE | As Supplied | After Recovery | Standard Length | |
| ID (MM,Min.) | Wall thickness(MM) | ID(MM) | ||
| 2.5 | 2.5 | 0.2±0.02 | 1.9 | 1000mm/Pcs |
| 3 | 3 | 0.2±0.02 | 2.3 | 1000mm/Pcs |
| 3.5 | 3.5 | 0.2±0.02 | 2.6 | 1000mm/Pcs |
| 4 | 4 | 0.2±0.02 | 3 | 1000mm/Pcs |
| 4.5 | 4.5 | 0.2±0.02 | 3.5 | 1000mm/Pcs |
| 5 | 5 | 0.2±0.02 | 3.8 | 1000mm/Pcs |
| 6 | 6 | 0.2±0.02 | 4.6 | 1000mm/Pcs |
| 7 | 7 | 0.2±0.02 | 5.4 | 1000mm/Pcs |
| 8 | 8 | 0.2±0.02 | 6.2 | 1000mm/Pcs |
| 9 | 9 | 0.2±0.02 | 6.9 | 1000mm/Pcs |
| 10 | 10 | 0.2±0.02 | 7.7 | 1000mm/Pcs |
| 12 | 12 | 0.2±0.02 | 9.2 | 1000mm/Pcs |
| 13 | 13 | 0.2±0.02 | 10 | 1000mm/Pcs |
| 14 | 14 | 0.2±0.02 | 10.8 | 1000mm/Pcs |
| 15 | 15 | 0.2±0.02 | 11.5 | 1000mm/Pcs |
| 16 | 16 | 0.2±0.02 | 12.3 | 1000mm/Pcs |
| 17 | 17 | 0.2±0.02 | 13.1 | 1000mm/Pcs |
| 18 | 18 | 0.2±0.02 | 13.8 | 1000mm/Pcs |
| 20 | 20 | 0.2±0.02 | 15.4 | 1000mm/Pcs |
| 21 | 21 | 0.2±0.02 | 16.2 | 1000mm/Pcs |
| 22 | 22 | 0.2±0.02 | 16.9 | 1000mm/Pcs |
| 25 | 25 | 0.2±0.02 | 19.2 | 1000mm/Pcs |
| 28 | 28 | 0.2±0.02 | 21.6 | 1000mm/Pcs |
| 30 | 30 | 0.2±0.02 | 23.1 | 1000mm/Pcs |
| 33 | 33 | 0.2±0.02 | 25.4 | 1000mm/Pcs |
| 35 | 35 | 0.2±0.02 | 27 | 1000mm/Pcs |
| 38 | 38 | 0.2±0.02 | 29 | 1000mm/Pcs |
| 40 | 40 | 0.2±0.02 | 31 | 1000mm/Pcs |
| 45 | 45 | 0.2±0.02 | 35 | 1000mm/Pcs |
| 50 | 50 | 0.2±0.02 | 39 | 1000mm/Pcs |
| 55 | 55 | 0.2±0.02 | 42 | 1000mm/Pcs |
| 60 | 60 | 0.2±0.02 | 46 | 1000mm/Pcs |
| 65 | 65 | 0.2±0.02 | 50 | 1000mm/Pcs |
| 70 | 70 | 0.2±0.02 | 54 | 1000mm/Pcs |
| 75 | 75 | 0.3±0.02 | 58 | 1000mm/Pcs |
| 80 | 80 | 0.3±0.02 | 62 | 1000mm/Pcs |
| 90 | 90 | 0.3±0.02 | 70 | 1000mm/Pcs |
| 100 | 100 | 0.3±0.02 | 77 | 1000mm/Pcs |
| 110 | 110 | 0.3±0.02 | 84 | 1000mm/Pcs |
| 120 | 120 | 0.3±0.02 | 92 | 1000mm/Pcs |
| 150 | 150 | 0.5±0.02 | 116 | 1000mm/Pcs |
| 200 | 200 | 0.5±0.02 | 154 | 1000mm/Pcs |
| 250 | 250 | 0.5±0.02 | 193 | 1000mm/Pcs |
FAQ
1) What’s the delivery time of free heat shrink sample?
Within 1 day
2) Which payment terms and method do you accept?
TT in advance, or 30% TT in advance, 70% balance by copy of B/L
Pay to: our company account / on line of alibaba / Western Union / Paypal, etc
3) How these heat shrink tube will be freight please?
For one to two cartons of goods, freight by the agent of DHL,UPS,TNT,Fedex.
For LCL goods will be freight by sea or air.
Usually we can find the most competitive freight cost for our clients.
4) How to Warrant your heat shrink tubing quality?
Step1. Clarify the size, color, material, packing, and all other detail requirement before production;
Step 2. Strictly inspection made during production and before goods delivery from our factory.
Step 3. After goods received by client, once client feedback any technical mistake within 2 months, and proved this mistake/problem made by our production, we’ll provide qualified goods for free.
