SP 320 with PFC function 320w power supply 48v 6.7a
- Category: >>>
- Supplier: Yueqing Okey trade Co Ltd
Share on (1600614547160):
Product Overview
Description
Product Description
Features:
•Universal AC input/ full range
•Built-in active PFC function,PF>0.95
•Protections: Short circuit/ Over load/ Over voltage/ Over temperature
•Forced air cooling by built-in DC fan
•Fixed switching frequency at 100KHz
•2 years warranty
SPECIFICATIONS | |||||||||
OUTPUT | |||||||||
Model | SP-320-5 | SP-320-7.5 | SP-320-12 | SP-320-13.5 | SP-320-15 | SP-320-24 | SP-320-27 | SP-320-48 | |
DC Voltage | 5V | 7.5V | 12V | 13.5V | 15V | 24V | 27V | 48V | |
Rated Current | 55A | 40A | 25A | 22A | 20A | 13A | 11.7A | 6.7A | |
Current Range | 0-55A | 0-40A | 0-25A | 0-22A | 0-20A | 0-13A | 0-11.7A | 0-6.7A | |
Rated Power | 275W | 300W | 300W | 297W | 300W | 312W | 315.9W | 321.6W | |
Ripple & Noise | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 200mVp-p | 240mVp-p | |
DC Adjustment Range | ±10% | ±20% | -16%,+10% | ±11% | -10%,+20% | -16%,+10% | -4%,+18% | -15%,+17% | |
Voltage Tolerance | ±2% | ±2% | ±1% | ±1% | ±1% | ±1% | ±1% | ±1.0% | |
Line Regulation | ±0.5% | ±0.5% | ±0.3% | ±0.3% | ±0.3% | ±0.2% | ±0.2% | ±0.2% | |
Load Regulation | ±1% | ±1% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
Setup, Rise, Hold Up Time | 800ms,50ms,16ms/230VAC 2500ms,50ms,16ms/115VAC at full load | ||||||||
INPUT | |||||||||
Voltage Range | 88~264VAC 120~370VDC frequency: 47~63 Hz | ||||||||
AC Current | 5A/115 VAC 2.5A/230VAC | ||||||||
Power Factor | PF>0.95/230VAC,PF>0.98/115VAC at full load | ||||||||
Efficiency | 79% | 83% | 86% | 86% | 86% | 87% | 88% | 89% | |
Inrush Current | 20A/115VAC 40A/230VAC | ||||||||
Leakage Current | <1mA/240VAC | ||||||||
PROTECTION | |||||||||
Over Load | 105%-135% rated output power | ||||||||
Protection type: Hiccup mode, recovers automatically after fault condition is removed | |||||||||
Over Voltage(V) | 115%~135% | ||||||||
Protection type: Shut down o/p voltage, re-power on to recover | |||||||||
Over Temp. | Shut down o/p voltage, recovers automatically after temperature goes down | ||||||||
ENVIRONMENT | |||||||||
Working Temp. Humidity | -20℃~+65℃; 20%~90 % RH non-condensing | ||||||||
Storage Temp. Humidity | -40℃~+85℃; 10%~95 % RH | ||||||||
Temp. Coefficient | ±0.03%/℃(0~50℃) | ||||||||
Vibration | 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes | ||||||||
SAFETY | |||||||||
Withstand Voltage | I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG: 0.5KVAC | ||||||||
Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC/25℃/70% RH | ||||||||
STANDARD | |||||||||
Safety Standard | Design refer to UL60950-1,TUV EN60950, CCC | ||||||||
EMC Standard | Design refer to EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11;ENV50204,EN55024, light industry level, criteria A | ||||||||
OTHERS | |||||||||
Dimension | 215*115*50mm (L*W*H) | ||||||||
Weight | 1.1Kg/pc; 12pcs/14kg/0.95CUFT | ||||||||
NOTE | 1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. | ||||||||
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12″twisted pair-wire terminated with a 0.1μf & 47μf parallel capacitor. | |||||||||
3. Tolerance: includes set up tolerance, line regulation and load regulation. | |||||||||
4. The power supply is considered a component which will be installed into final equipment. The final equipment must be re-confirmed that it still meets EMC directives. | |||||||||
Company Information
If you have any questions,please contact
customer service
FAQ
1. Q: How many voltage you can supply?
A:5V,9V,12V,13.8V,15V,18V,24V,36V,48V,50V,60V,110V(Depend on items).
2. Q: How many current you can supply?
A:0.5A,1A.1.5A.2A,3A.4A,5A,6A,10A,15A,20A,30A,40A,50A,60A,80A.
3. Q: How about the quality?
A: We have the best professional and experienced engineer and strict QA and QC system.Repair rate under 0.1%-0.2%.
4.Q:What's your delivery time?
A: Sample or small quantity order delivery in3-5 working days, large quantity order normally ship in 10-20working days.
5.Q: Can we be your distributor?
A: Yes, we arelooking for distributor and agent from all over the world for switching power supply, power inverter, solar controller, scrolling system. If you have any interest, pls feel free to contact us.
6.Q:What's kind of payment you accept?
A:T/T,Alibaba Trade Assurance,L/C, PayPal, Western Union, MoneyGram, O/A(negotiate).
7. Q:What's your MOQ?
A: 1 piece.
8. Q:Do you accept OEM &ODM?
A: Yes,
