ANYTONE DORIS Standard 40 Channels AM FM SSB CB Radio 4W Long Range Walkie Talkie 26.565 27.99125MHz Ham Radio
ANYTONE DORIS Standard 40 Channels AM FM SSB CB Radio 4W Long Range Walkie Talkie 26.565-27.99125MHz Ham Radio
ANYTONE DORIS Standard 40 Channels AM FM SSB CB Radio 4W Long Range Walkie Talkie 26.565-27.99125MHz Ham Radio
ANYTONE DORIS Standard 40 Channels AM FM SSB CB Radio 4W Long Range Walkie Talkie 26.565-27.99125MHz Ham Radio
ANYTONE DORIS Standard 40 Channels AM FM SSB CB Radio 4W Long Range Walkie Talkie 26.565-27.99125MHz Ham Radio
ANYTONE DORIS Standard 40 Channels AM FM SSB CB Radio 4W Long Range Walkie Talkie 26.565-27.99125MHz Ham Radio
ANYTONE DORIS Standard 40 Channels AM FM SSB CB Radio 4W Long Range Walkie Talkie 26.565-27.99125MHz Ham Radio

ANYTONE DORIS Standard 40 Channels AM FM SSB CB Radio 4W Long Range Walkie Talkie 26.565 27.99125MHz Ham Radio

Share on (1600615719000):


Price:$78.00

Quantity:


Product Overview

Description







Product Description


MODEL NO.: DORIS -an Universal Mounted Mobile CB Transceiver
Frequency: HF：24.715-30.105MHz
HAM：28.000-29.695MHz CB : 26.565-27.99125MHz

Two Version:
1.Low power output version
12/24V
AM: 4W/8W
FM: 4W/8W/15W
2.High power output version
12V
AM: 4W/12W
FM: 4W/12W/30W

Functions:
●A versatile CB radio, suitable to mount on any surface or in a DIN compartment
●12/24 V power supply capability
●With all the accessories included in the package, you can hang it on the windscreen or place it on the dashboard
●Multi-band, both FM/AM, therefore suitable to communicate beyond national borders, adapting to European frequencies
●Large TFT colour display with easy to read messages
●Packed with functions PA,
●Dual Watch (to constantly monitor 2 channels)
●Roger Beep
●CTCSS/DCS funtion
●5K setting
●Scan range setting,
●Noise reduction function
●Time out timer setting
●VOX function
............




GENERAL
Frequency Range
26.565-27.99125MHz
Frequency Tolerance
±5.0ppm
Input Voltage
12/24V
Ferquency Control
PLL Synthesizer
Operating Temperature Range
-20℃ TO + 55℃

Current Drain
Transmit
3A MAX
Receive
Squelched 0.3A
VOL Max
0.8A
TRANSMITTER
Power Output
4 Watts FM/AM
Transmission interference
inferior to 4nW(-54dBm)
Frequency Response
300-3000Hz
Modulated signal distortion
inferior to 5%
Output Impedance
50 ohms
RECEIVER


Sensitivity
Less than 1uV for 10dB(S+N)/N
Image Rejection
70dB
Adjacent Channel Rejection
60dB
IF Frequencies
1st 10.695MHz
2nd 455KHz
Automatic Gain Control(AGC)
Less than 10dB change in audio
Output for inputs from 10 to 50000uV
Squelch
less than 1uV
Audio Output Power
1Watts
Frequency Response
300-3000Hz
****Note: Specifications are subject to change without notice due to technical improvements.


Below is our factory introduction, for more detail informations, plz contact sale16833@qxdz.cn


Recommend Products




Company Profile






FAQ


1.Who are we?
We are based in Fujian, China, start from 1993,sell to mainly Western Europe & North America, also
Eastern Asia, Oceania,Southeast Asia, Eastern Europe, South America. There are total about 300+
people in our factory.We have our own brand "ANYTONE"

2.How to place order?
Inquiry => We quote => Price confirmed => We send you Invoice => Payment => Shipping => You receive it

3.How can we guarantee quality?
Always a pre-production sample before mass production;
Always materials inspection from the start and final Inspection before shipment

4.Warranty
18 months warranty for radio and 6 months for accessories.
If you find any defective,please contact us within 3 days after you receive,thanks.

5.what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese
