CDDE High Quality Walking Full DC Motor Reach Stacker Forklift 1.5 ton Electric Pallet jack Stacker
- Category: >>>
- Supplier: Wemalift (hangzhou) Equipment Co. Ltd.
Share on (1600617839312):
Product Overview
Description
Warehouse Used Cheap Pallet Stacker with Electric Lifting
Product Description
Specification
Model | CDD-E | ||||||||
Capacity(kg) | 1500 | ||||||||
Max.lifting height(mm) | 1600 | 2000 | 2500 | 3000 | 3500 | ||||
Height, Mast Extended(mm) | 2065 | 2532 | 3032 | 3532 | 4032 | ||||
Height, Mast Lowered (mm) | 2065 | 1565 | 1815 | 2065 | 2312 | ||||
Overall Width(mm) | 800 | ||||||||
Overall length(mm) | 1860 | ||||||||
Leg Length (mm) | 1000 | ||||||||
Fork length(mm) | 1150 | ||||||||
Single Leg width(mm) | 100 | ||||||||
Overall Fork width(mm) | 560/680 | ||||||||
Min. Fork Height(mm) | 160 | ||||||||
Ground clearance(mm) | 30 | ||||||||
Lift speed, Unladen/laden(m/s) | 0.15/0.1 | ||||||||
Lower speed, Unladen/laden(m/s) | 0.13/0.15 | ||||||||
Load Center | 500 | ||||||||
Turning Radius | 1280 | ||||||||
Aisle Width:1000x1200 pallet crossways | 1986 | ||||||||
Aisle Width:1000x1200 pallet lengthways | 1920 | ||||||||
Front wheel/QTY | 80x70/4 | ||||||||
Drive wheel/QTY | 210x75/1 | ||||||||
Balance wheel/QTY | 115x55/1 | ||||||||
Battery | 2x12V/85AH | ||||||||
Charger | 24V/15AH | ||||||||
Lift Pump DC | 2.2KW | ||||||||
Drive pump DC | 0.75KW | ||||||||
