Product Overview
Description
Product Introduction
High Speed Stable Production Line machinery Of Stainless Steel Pipe Making Machine Welded Tube Mechanics Manufacturing Supplier
TUBE MATERIAL:Stainless Steel/Copper/Carbon Steel/Iron/Galvanized Etc
PIPE SHAPE:Round/Square/Rectangle/Special-shaped Etc
USDAGE:Pipes for Furniture, Construction, Municipal Facilities etc Fields
Product Model Parame
High Speed Stable Production Line machinery Of Stainless Steel Pipe Making Machine Welded Tube Mechanics Manufacturing Supplier
| MODEL | GXG-S40 | GXG-40 | GXG-L40 | GXG-50 | GXG-60 |
| Round Tube Range (mm) | Ø5—31.8 1/5”—1-1/4” | Ø9.5—50.8 3/8”—2” | Ø15.9—63.5 5/8”—2-1/2” | Ø19.1—76.2 3/4”—3” | Ø31.8—114.0 1-1/4”—4-1/2” |
| Square Tube Range (mm) | 5*5—25*25 | 8*8—40*40 | 13*13—50*50 | 20*20—60*60 | 30*30—90*90 |
| Wall Thickness Range (mm) | 0.15—0.8 / 0.5 | 0.23—1.5 /1.2 | 0.30—1.8 / 1.3 | 0.35—2.5 / 1.5 | 0.55—3.0 / 2.0 |
| Horizontal Shaft Diameter(mm) | Ø40 | Ø40 | Ø45 | Ø50 | Ø60 |
| Vertical Shaft Diameter(mm) | Ø20 | Ø25 | Ø25 | Ø30 | Ø35 |
| Main Motor Power(kw) | 5.5 | 7.5 | 7.5 | 11 | 15 |
| Installation Dimension(L*W m) | 21*1 | 22*1.2 | 23*1.2 | 25*1.3 | 28*1.5 |
| Rated Voltage(v) | 220 / 380 / 415 / 440 | ||||
Product Description
High Speed Stable Production Line machinery Of Stainless Steel Pipe Making Machine Welded Tube Mechanics Manufacturing Supplier
