Microsensor ATEX IECEX Hydrostatic Level Sensor Submersible Level Transmitter for Fuels Ethanol Waste Water Tank IP68 MPM426WPF
- Category: Measuring & Gauging Tools >>>
- Supplier: Micro,Sensor,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
Basic Information
Microsensor's MPM426WPF is the submersible level transmitter with the fully welded structure. The product utilizes a piezoresistive sensor with proved long term stability and reliability and a special digital compensation circuit that is housed in a rugged stainless steel housing. It offers an integrated structure, supports standard outputs, and cable options of multiple material for a wide range of operation temperature.
MPM426WPF is mostly used in the level monitoring of refined oils, such as gasoline,diesel, kerosene, etc. with high requirements for wear resistance, protection, or explosion-proof.
MPM426WPF is mostly used in the level monitoring of refined oils, such as gasoline,diesel, kerosene, etc. with high requirements for wear resistance, protection, or explosion-proof.
Application
* Gasoline, diesel, methanol, ethanol storage tank
* Biofuel tank
* Ballast tank
* Underground water level in mining areas
* Gasoline, diesel, methanol, ethanol storage tank
* Biofuel tank
* Ballast tank
* Underground water level in mining areas
* Wastewater level
Feature
* Low power consumption
* Wide operation temperature range* For harsh operating conditions
* Mulitple output signals available
* Integrated temperature measurement
* Magnetic end cap for movable tanks
* NPT1/4 male thread for process connection available
* Approved for use in hazardous areas
Specification
Pressure range | 0mbar~200mbar...350bar |
Pressure type | Gauge, absolute, sealed gauge |
Overpressure | < 2 times FS |
Long-term stability | < ±0.2% FS/ year |
Compensated temperature | -10C ~60C |
Operation temperature | -20°C ~80°C (PUR cable); -10°C~70°C (PVC/PE cable) |
Storage temperature | -30°C ~85°C (PUR cable); -20°C~85°C (PVC/PE cable) |
Vibration | 20g, 20Hz~2000Hz |
Shock | 20g, 11ms |
Protection rating | IP68 |
FAQ
Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer since 1971 on Pressure/ Level/ Temperature/ Flow transmitters with 4~20mA, Hart, Rs485 & Modbus protocols, pressure sensors with SDI, I2C, 4~20mA, 0.5~4.5V and etc, and wireless IOT measurement transmitters. We provide high-quality products with high competitive factory prices.
Q: What's your quality control system?
A: As an ISO9001:2008 certificated manufacturer, we have a strict quality control system, and each product is done with fatigue testing, calibration, temperature compensation before shipment. High quality is guaranteed.
Q: Is there MOQ with your product?
A: MOQ is 5, 1pc for testing is acceptable.
Q: Do you provide customized products?
A: Yes, we can print your logo on our products; OEM, ODM & customization are welcomed.
Q: What is the warranty of your products? And after-sales service?
A: Our warranty time is 12 months after shipment, and our after-sales will respond with your questions in 24hrs, remote
instruction by PC network is always available.
Q: What is the lead time of your product?
A: We are a factory, our lead time is always within 10~15 working days for products without customization, but lead-time will vary based on different products. You can check detailed lead-time with our sales.
Q: What international certificates do you have for your products?
A: We have CE, RoHS, UL, ATEX as well as ship-use DNV, etc.
