Provender particles sieving easy cleanning system straight flow vibrating screen machine
- Category: >>>
- Supplier: Xinxiang Dezhong Intelligent Equipment Co. Ltd
Share on (1600619449117):
Product Overview
Description
Product Description
Rotary vibrating sieve use a vertical vibration motor as vibration source.The upper and lower ends of the motor are equipped with eccentric weights to change the rotary motion of the motor into horizontal ,vertical and inclined three -dimensional motions,and passed the force to the screen surface .Adjust the angle of upside and downside hammer to change the movement of the material on the screen surface.
Product Paramenters
Product number | power （kW) | Motor speed （r/min） | Screen diameter （mm） | Dimensions （mm） |
SZS-600 | 2×0.18 | 1460 | Φ560 | 1150×600×550 |
SZS-800 | 2×0.18 | 1460 | Φ760 | 1360×800×600 |
SZS-1000 | 2×0.25 | 1460 | Φ930 | 1600×1000×700 |
SZS-1200 | 2×0.55 | 1460 | Φ1160 | 2000×1200×900 |
SZS-1500 | 2×0.75 | 1460 | Φ1430 | 2350×1500×1000 |
Application
Particle ,granular
Powder
Liquid
Food industry
wheat flour, salt ,sugar,starch ,coconut powder ,coffee powder ,milk powder ,spice powder ,etc
Chemical industry
resin powder, washing powder, soda ash, etc
Electromagnetic &Metallurgy Abrasives, ceramics industry:
titanium oxide, zinc oxide, metal powder,graphite,alumina, quartz sand,. etc
titanium oxide, zinc oxide, metal powder,graphite,alumina, quartz sand,. etc
1.Q: How To Order ?
Step 1, please tell us what model and quantity you need;
Step 2, then we will make you to confirm the order details;
Step 3, when we confirmed everything, can arrange the payment;
Step 4, finally we deliver the goods within the stipulated time.
2.After-sales Service 1 year warranty for all kinds of products;
3.Payment T/T, Western Union, Money gram ,Escrow.
4.Transportation Transported by DHL , UPS, EMS, Fedex ,Air freight. sea freight.
5.Do you support drop shipping?
Yes,your drop shipping is available.
Step 1, please tell us what model and quantity you need;
Step 2, then we will make you to confirm the order details;
Step 3, when we confirmed everything, can arrange the payment;
Step 4, finally we deliver the goods within the stipulated time.
2.After-sales Service 1 year warranty for all kinds of products;
3.Payment T/T, Western Union, Money gram ,Escrow.
4.Transportation Transported by DHL , UPS, EMS, Fedex ,Air freight. sea freight.
5.Do you support drop shipping?
Yes,your drop shipping is available.
