BIOBASE Gas Chromatograph BK GC112A with FID detector GC machine Cromatografo
- Category: >>>
- Supplier: Medfuture,Biotech,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Gas Chromatograph BK-GC112A | ||||||||
Specification
Model | BK-GC112A | ||||
Oven | Temp. Range | RT+5℃~400℃ | |||
Temp. Accuracy | ±0.02℃ | ||||
Temp. Program | 9-phase/ 10 platform | ||||
Max Temp. Heating Rate | 60℃/min | ||||
Sample injector | Temp. Range | RT+7℃~420℃ | |||
Column or split injector can be installed. | |||||
Split mode can directly set the split ratio. | |||||
Constant pressure mode. | |||||
A separate injection system is connected. | |||||
Detector | Temp. Range | RT+7℃~420℃ | |||
Hydrogen Flame Ionization Detector (FID) | Logarithmic amplifier | ||||
High voltage switch control | |||||
Baseline signal display | |||||
Ignition coil control | |||||
Detection limit:≤3*10-12g/s (Sample: n-hexadecane) | |||||
Dynamic range: 107 | |||||
Thermal Conductivity Detector (TCD) (Optional) | Bridge voltage switch control | ||||
Bridge current setting: 0-220mA | |||||
Sensitivity: 6000mv.ml/mg | |||||
Dynamic range: 105 | |||||
Power Supply | AC220V±10%, 50/60Hz | ||||
Standard Accessory | FID detector, Capillary injection system, Chromatography workstation software. | ||||
Optional Accessory | TCD detector, Chromatographic column, Gas purifier. | ||||
Package Size (W*D*H) | 1020*660*740mm | ||||
Gross Weight | 82kg | ||||
