Customize Other Multilayer Metal Core Pcb Circuit Boards Hdi 94v0 Rohs Electronic Aluminum Pcba Assembly Service Manufacturer

Share on:

Price:$0.90 - $5.00
Price in USD:Details


Product Overview


YUE TONG provides Electronic Manufacturing Services (EMS) for your products that require surface mount, through hole, BGA and mixed technology.
Our main services include PCB assembly (Electronic assembly), component procurement and PCB fabrication from quick turn, sample run to volume production.
Our customers are who of the Medical, Instrumentation, Intelligent home, Automotive, Consumer electronics industry and Robotics industries.
Full range of PCB manufacturing and assembly services to fit all of your printed circuit board needs.


Product description

Layer count

FR-4, High TG FR4, aluminium, FPC
Teflon,PTFE (F4B,F4BK), Rogers (4003,4350,5880)
Max board dimensions
Board shape
Board type
Board cutting
Shear,V-score,tab-routed,counter sunk
Board thickness
0.2~8.0mm, Flex 0.1~0.25mm
Thickness Tolerance
Min line width / space
Minimum Drilling Hole (Mechanical)
Minimum laser hole
Blind Hole/buried plate

Hole Position/hole Tolerance
InnerLayer Copper Thickness
0.5-3 oz
OutLayer Copper Thickness
0.5-4 oz
Impedance control tolerance
Surface finish
HASL,Lead free HASL,ENIG,Immersion Tin,Immersion Silver,OSP...
Solder mask
Double-sided green,red,white,blue,black,etc
Double-sided or single-sided in white,black,or negative
PCB Testing
E-test, Flying probe test
Acceptable File Format
Gerber RS-274X,274D,AutoCAD'S DXF,DWG,Pro-E,Ki-CAD
Quality Standards
IPC-A-600F and MIL-STD-105D CHINA GB<4588>

Types of PCB assembly
SMT (Surface Mounted Technology)

THT (Through Hole Technology)

Mixed (surface mount and through hole) technology

Cable assembly

Passive Component: small as 01005, 0201
Fine Pitch Parts: 0.25mm fine pitch parts
Max Component Height: 25mm(SMT), Top 120mm/Bot 15mm (Wave-Solder)
Component Package
Reels, cut tape, Tube and tray, Loose parts and bulk

Board Dimension
Min Board Size: No Limited
Max Board Size: 680 x 500mm
Board Shape
We can assemble boards in Rectangular, Circular and irregular
Board Type
Rigid PCB, Flexible PCB, Rigid-flex PCB
Assembly process
Leaded/Lead-Free (RoHS)

Design file format
Gerber RS-274X
BOM (Bill of Materials) (.xls, .csv, . xlsx)
Centroid(Pick-N-Place/XY file)

Electrical testing
X-ray Inspection
AOI (Automated Optical Inspection)
Functional testing
ISO13485, IATF16949, ISO9001,ISO14001
Quality Standards
IPC-A-600/IPC-A-610 compliance
Type of Service
Turn-key, partial turn-key or consignment
Plastic case,metal case,screen
Wish You Have A Pleasant Purchasing Time! Pls Click >>Contact Us


AOI Test
Checks for solder paste
Checks for components down to 0201"
Checks for missing components, offset, incorrect parts, polarity

X-Ray Inspection
X-Ray provides high-resolution inspection
Micro BGAs
Chip scale packages
Bare boards

 Power-up Test
 Advanced Function Test
 Flash Device Programming
 Functional testing

Q1: Do you have a price list?
A: We are OEM Manufacturer. We produce products per Customer’s designs and instructions. Hence we don’t have a price list.

Q2: What’s your MOQ for PCB, PCBA?
A: No MOQ for PCB and PCBA. We can do prototype and mass production as well.

Q3: Are my files safe?
A: We can sign an NDA(Non-disclosure agreement).Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.All documents from customers are never shared with any third parties.

Q4: What is needed for PCB & PCBA quotation?
A: PCB: Quantity,Gerber file and technic requirements( board material, board size, surface finish treatment, copper thickness, board thickness).PCBA: PCB information,BOM,Testing documents.

Q5: What file formats do you accept for PCB and assembly?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE,P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

Q6: Can you procure all parts in BOM for us?
A: YES, we can source all parts as per your bom list required.

Q7: Do you have after-sales product servicing available for your customers?
A: Yes, for any quality problems, we will take our responsibility to solve it for you at any time.

Providing electronic contract manufacturing service for oem PCB PCBA.
For all your PCB needs, Call or email your gerber file and bom list to us right now.
