Model | WP4.1NC130-21E220 | WP4.1NC163-21E220 | WP4.1NC177-23E220 | WP3NC160-30E220 | |||
Horsepower (Hp) | 130 | 163 | 177 | 190 | |||
Rated power (Kw/Ps) | 95 | 120 | 130 | 140 | |||
Rated speed(r/min) | 2100 | 2100 | 2300 | 2600 | |||
Intake method | supercharged Intercooled | supercharged Intercooled | |||||
Fuel System | Electronic control common rail | Electronic control common rail | Electronic control common rail | Electronic control common rail | |||
Connection size | Flywheel SAE14, Flywheel Housing SAE1 | Flywheel SAE14, Flywheel Housing SAE1 | Flywheel SAE14, Flywheel Housing SAE1 | Flywheel SAE14, Flywheel Housing SAE1 | |||
Cylinders - Bore x Stroke (mm) | 105×118(mm) | 6-131x145 | 6-131x145 | 6-131x145 | |||
Weight(kg) | 500 | 1210 | 1210 | 1210 | |||
LxWxH(mm) | 960×700×850(mm) | 1702x1005x1063 | 1567x1015x1097 | 1567x1015x1097 | |||
Firing order | 1-3-4-2 | 1-5-3-6-2-4 | 1-5-3-6-2-4 | 1-5-3-6-2-4 | |||
Displacement (L) | 4.08L | 11.73 | 11.73 | 11.73 | |||
Min.specific fuel consumption (g/kWh) | 191 (g/kW h) | W198 | W198 | W198 | |||
Specific oil consumption (g/kWh) | 0.1(g/kW·h) | W0.5 | W0.5 | W0.5 | |||
Crankshaft rotation direction (see from power output | Counterclockwise (towards the power output) | Counterclockwise (towards the power output) | Counterclockwise (towards the power output) | Counterclockwise (towards the power output) | |||
Min.steady working speed (r/min) | 700 | 650 | 650 | 650 | |||
Starting mode | Electric start | Electric start | Electric start | Electric start | |||
Matched reduction gearbox | Hangchi HCV230, HCQ300, Jiangnan JS441, Jiangnan LQ200-1 | Hangchi HCV230, HCQ300, Jiangnan JS441, Jiangnan LQ200-1 | Hangchi HCV230, HCQ300, Jiangnan JS441, Jiangnan LQ200-1 | Hangchi HCV230, HCQ300, Jiangnan JS441, Jiangnan LQ200-1 | |||
Type | Vertical, inline, water-cooled, four-stroke | Vertical, inline, water-cooled, four-stroke | Vertical, inline, water-cooled, four-stroke | Vertical, inline, water-cooled, four-stroke | |||
Certificate/Emission | CCS,ZC/National II, EIAPP | CCS/National II, EIAPP | CCS/National II,EIAPP | CCS/National II, EIAPP | |||
