8CH 4MP OEM IP POE NVR Kit ColorVu Smart Dual Light IR Built in Mic 4CH Network Security CCTV Camera System
8CH 4MP OEM IP POE NVR Kit ColorVu Smart Dual Light IR Built-in Mic 4CH Network Security CCTV Camera System
8CH 4MP OEM IP POE NVR Kit ColorVu Smart Dual Light IR Built-in Mic 4CH Network Security CCTV Camera System
8CH 4MP OEM IP POE NVR Kit ColorVu Smart Dual Light IR Built-in Mic 4CH Network Security CCTV Camera System
8CH 4MP OEM IP POE NVR Kit ColorVu Smart Dual Light IR Built-in Mic 4CH Network Security CCTV Camera System
8CH 4MP OEM IP POE NVR Kit ColorVu Smart Dual Light IR Built-in Mic 4CH Network Security CCTV Camera System
8CH 4MP OEM IP POE NVR Kit ColorVu Smart Dual Light IR Built-in Mic 4CH Network Security CCTV Camera System

8CH 4MP OEM IP POE NVR Kit ColorVu Smart Dual Light IR Built in Mic 4CH Network Security CCTV Camera System

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description





. 8CH.265 8MP POE NVR, 4ch Playback
. 1ch RCA audio output/HDMI Audio output
. Support 1*10TB HDD, HDMI/VGA output
. 1ch RCA audio output/HDMI Audio output
. Support 1*10TB HDD, HDMI/VGA output
. 1/3"CMOS sensor, 4MP Resolution, 3.6mm Lens, Smart Dual Light(20m IR+15m Flood Light), Mic. Audio in H.265 POE IP Turret Camera


Product Description










Model
NVR301-08LS3-P8
NVR301-16LS3-P8
Video/Audio Input
IP Video Input
8-ch
16-ch
Network
Incoming Bandwidth
64Mbps
Outgoing Bandwidth
48Mbps
Remote Users
128
Protocols
TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP
Video/Audio Output
HDMI/VGA Output
HDMI:
4K(3840x2160)/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
VGA:
1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
Recording Resolution
4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output
1-ch, RCA
Audio Compression
G.711A, G.711U
Synchronous Playback
8-ch
16-ch
Live view display
1/4/6/8/9
1/4/6/8/9/16
Corridor Mode Screen
3/4/5/7/9
3/4/5/7/9/10/12/16
Snapshot
FTP/Schedule/Event Snapshot
1-ch snapshot, up to D1 resolution
Decoding
Decoding format
Ultra 265/H.265/H.264
Live view/Playback
4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability
1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 4 x 1080p@30, 8 x 720p@30
1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 4 x 1080p@30, 8 x 720p@30, 16 x D1@25
Hard Disk
SATA
1 SATA interface
Capacity
up to 10TB for each disk
Smart
VCA Search
Behavior Search
Smart Intrusion Prevention (SIP) by Camera
4-ch(supports channel 1-4; Alarm only, no image)
General Alarm
General Alarm
Motion, Tampering, Video Loss, Alarm Input
Alert Alarm
IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full,
Recording/Snapshot Abnormal
External Interface
Network Interface
1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface
Rear panel: 2 x USB2.0
RS232
NA
RS485
NA
Alarm In
NA
Alarm Out
NA
PoE
Interface
8 RJ45 10M/100M self-adaptive Ethernet Interface
Max Power
Max 30W for single port
Max 75W in total
Supported Standard
IEEE 802.3at, IEEE 802.3af
General
Power Supply
52V DC
Power Consumption: ≤9 W (without HDD)
Working Environment
-10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing)
Dimensions (W×D×H)
270mm × 205mm × 46mm (10.6"×8.1"×1.8")
Weight (without HDD)
≤0.8 kg (1.76 lb)
Certification
Certification
CE, FCC, UL, ROHS, WEEE
CE
EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017
FCC
Part15 Subpart B, ANSI C63.4












Company Profile




FAQ


1. Who are we?
We are based in Guangdong, China, start from 2016, sell to North America(40.00%), Domestic Market(20.00%), Western Europe(20.00%), Eastern Asia(10.00%), Mid East(5.00%), Oceania(5.00%). There are total about 11-50 people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.

3.What can you buy from us?
CCTV Camera, IP Camera system, Wifi Camera system, Analog Camera system, NVR and DVR.

4. Why choose us?
Our company has more than 19 years experiences in advanced security & surveillance solutions. Products has spread all the world including Americas, Europe, Asia, Middle East etc.

5. What services can we provide?
Accepted Delivery Terms: FOB, EXW, Express Delivery；
Accepted Payment Currency: USD, CNY;
Accepted Payment Type: T/T,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish
