High Quality Piezoelectric Disc Pzt Material Ceramic Piezo Elements Piezoelectric Flexible For Ultrasonic Cleaner Machine
- Category: >>>
- Supplier: Hangzhou Altrasonic Technology Co. Ltd.
Share on (1600624434873):
Product Overview
Description
Size | Material | Capacitors (pf) | Quality factors (QM) | Resonant frequency (kHz) | Impedance (Ω) | Weight (g/pcs) | Transducer |
P43-Φ25*10*5mm | PZT4 | 1000pf | 1000QM | 62.14kHz | 13.82Ω | 10g | 35kHz/28kHz Welding Transducer |
P43-Φ30*12*5mm | PZT4 | 1285pf | 1000QM | 47kHz | 11.2Ω | 28g | 28kHz Welding Transducer |
P43-Φ35*15*5mm | PZT4 | 1800pf | 1000QM | 42.6kHz | 16Ω | 30g | 28kHz Cleaning Transducer |
P43-Φ35*15*5.5mm | PZT4 | 1700pf | 1000QM | 43KHz | 16Ω | 31g | 28kHz Cleaning Transducer |
P43-Φ38*15*5mm | PZT4 | 2500pf | 1000QM | 40.2kHz | 17Ω | 40g | 28kHz Cleaning Transducer |
P43-Φ45*15*5mm | PZT4 | 3200pf | 1000QM | 36.3kHz | 4Ω | 50g | 40kHz Cleaning Transducer |
P43-Φ50*17*5mm | PZT4 | 4000pf | 1000QM | 33kHz | 4Ω | 70g | 20kHz Welding Transducer |
P43-Φ50*17*6.5mm | PZT4 | 3000pf | 1000QM | 33.4kHz | 4.24Ω | 90g | 20kHz Welding Transducer |
P43-Φ50*20*6mm | PZT4 | 3300pf | 1000QM | 31.5kHz | 5.28Ω | 80g | 20kHz Welding Transducer |
P43-Φ50*20*6.5mm | PZT4 | 3000pf | 1000QM | 31.3kHz | 5.2Ω | 80g | 20kHz Welding Transducer |
P43-Φ60*30*10mm | PZT4 | 2300pf | 1000QM | 23.87kHz | 11Ω | 170g | 15kHz Welding Transducer |
P43-Φ65*30*10mm | PZT4 | 2500pf | 1000QM | 24kHz | 10Ω | 200g | 15kHz Welding Transducer |
P43-Φ50*2.6mm-S | PZT4 | 7800pf | 1000QM | 43.3kHz | 1.58Ω | 40g | 40kHz Cleaning Transducer |
P81-Φ25*10*5mm | PZT8 | 770pf | 800QM | 66.28kHz | 75.87Ω | 10g | 35kHz/28kHz Welding Transducer |
P81-Φ30*12*5mm | PZT8 | 1075pf | 800QM | 55kHz | 10Ω | 29g | 28kHz Welding Transducer |
P81-Φ35*15*5mm | PZT8 | 1400pf | 800QM | 45.77kHz | 13.1Ω | 30g | 28kHz Cleaning Transducer |
P81-Φ38*15*5mm | PZT8 | 1800pf | 800QM | 43.8kHz | 10.66Ω | 40g | 28kHz Cleaning Transducer |
P81-Φ38*15*6mm | PZT8 | 1500pf | 800QM | 43.64kHz | 13.84Ω | 40g | 28kHz Welding Transducer |
P81-Φ45*17*6.5mm | PZT8 | 2500pf | 800QM | 38.8kHz | 13.26Ω | 45g | 15kHz Welding Transducer |
P81-Φ50*17*6.5mm | PZT8 | 2700pf | 800QM | 35.3kHz | 6.5Ω | 90g | 20kHz Welding Transducer |
P81-Φ50*20*5mm | PZT8 | 3000pf | 800QM | 33.2kHz | 6.36Ω | 60g | 20kHz Welding Transducer |
P81-Φ50*20*6mm | PZT8 | 2700pf | 800QM | 33.1kHz | 6.6Ω | 80g | 20kHz Welding Transducer |
P81-Φ50*20*6.5mm | PZT8 | 2400pf | 800QM | 33.3kHz | 7.5Ω | 80g | 20kHz Welding Transducer |
FAQ
Q: Do you have it in stock?
A: Most of product available, if you have special requirement, pls feel free contact us, all issue can be solved through communication.
Q: Could you advise to us the design based on our special requirements or based on our object samples?
A: Of course, Our mission is make your idea show in the products itself.
Q: How long do you make the order product?
A: Our main mark is fast shipment, usually 3-7days after all details confirmed.
Q: . Do you have operating manual?
A: Of course, we will put it with the goods together. Also we will upload video in youtube and inform you the related link.
Q: How about the quality?
A: We have export to many other customers from all over the world,the feed back is good,quality is the first for our
factory, our main markets is USA and European etc
factory, our main markets is USA and European etc
Q: Could you do OEM?
A: Yes, of course.Everybody like OEM,We cherish the OEM VIP buyer like you,We can produce according customers’ requirement,just send us your requirements and design of drawing and sample
Q: Could we as your agent?
A: Of course.We are looking for sole agent in some Country who have the willing to cooperate with us for long business term.
Q: Terms of Payment
A: We have flexible and active payment if order huge.
Q: What custom requirements can you accept?
A: LOGO, product appearance, tool head size, packaging requirements, special customized requirements will be accepted,
etc.
etc.
