Batterie Speicher Solar 20kW Super Capacitor Lifepo4 Stacked Battery Pack Solar Energy Storage Power System For Solax HYB X3 G4

Share on (1600626311796):


Price:$520.00 - $680.00

Quantity:


Product Overview

Description



2.6kWh Module 51.2V 52Ah Super Capacitor Lifepo4 Stacked Battery Pack Solar Energy Storage Power System For Solax HYBRID X3 G4







Battery Module



Module Name
Ground Eco 2600-H
Energy Capacity
2.6kWh
Typical Voltage
51.2V
Ah
52Ah
Battery Type
Prismatic LiFePO4
Connection Method
Series connected for high voltage battery solution
Connector
No cable seat & plug
Weight
30KG per module
Battery System
System Voltage
204V
307V
409V
Working Voltage Range
168V~219V
252V~328V
336V~438V
Rated Capacity
10kWh
15kWh
20kWh
Ah
52Ah
Suggested SOC Range
10% ~ 100%
Usable Energy
9kWh
13.5kWh
18kWh
Peak Charge Current
50A
Rated Charge Current
35A
Charge Temperature
0℃ ~ 45℃
Discharge Temperature
-10℃~ 45℃
Cycle Life
6000 cycles @ 0.5C/0.5C, 25℃
Communication
CAN, RS485
Compatible Inverters
Growatt, Sofarsolar, Deye, GoodWe, Luxpower
Design Life
10 years
Dimensions
100cm x 57cm x 22cm
130cm x 57cm x 22cm
165cm x 57cm x 22cm
Display
Indicators








Case show






Why choose us




Factory introduction








Product Quality




FAQ


Battery Cell\t\t\t
\t1:\tWhat battery cell you are using?\t
We are using BYD or Gotion brand new prismatic cell. If necessary, please contact us for battery cell specifications.
\t2:\tHow many cycles can achieve for your battery cells?
\tBYD and GOTION brand new cells can achieve 6000 cycles @ 25℃, 0.5C conditions. Also please know usually 1C condition is about 3500 cycles.

Low Voltage Battery
1:Which hybrid inverter your battery BMS has been communicated\t
Our BMS has built protocol communication with most of inverter brands in market. You can please find the brnad information above picture.
\t\t\t
High Voltage Battery\t
1:Which hybrid inverter your high voltage battery BMS has been communicated
\tOur high voltage battery BMS has built protocol communication with Growatt, Sofarsolar, Goodwe, INVT, Megarevo etc brand three phase hybrid inverters.
\t2:\tWhy we use high voltage battery?\t
High voltage battery always works with three phase hybrid inverters, which need a higher battery output. So we need high voltage battery solution to achieve a bigger kW power.
\t3:\tHow much total voltage I need?
\tThis depends on inverter battery side specifications. For three hybrid inverter, it is always around 150V to 600V. We just need to consider this HV battery system volatge is in this range.

Warranty\t\t\t
\t1:What's your warranty years?
\tWe offer standard factory warranty which is valid 10 years for battery product, from the date of installation or no more than 10 and a half years from the delivery date from factory. The battery capacity will be no less than 70% within 10 years or 10MWh battery through put per kWh of the initial installation date by conditions charge rate is no more than 0.5C, and environment temperature should be in the range of 0℃ to 30℃.
\t2:If battery has issues, how you proceed for warranty?
\tOur engineer will remotely check the issues by software, this need local installer assistance. If it is software issue, the battery can be repaired by firmware update. If it is battery hardware issue, we will send the battery module or BMS to customer as the replacement.
\t\t\t
Service\t\t\t
\t1:Can you offer OEM or ODM?
\tYes, we are LFP battery specialized solution provider mianly in energy storage field. You can please inform us your applications, inverter brand and model name. We will select or customize LFP battery system for you.
