Mini Size Agm Sealed Lead Renewable Energy 12v Acid Battery 9a
- Category: >>>
- Supplier: Guangzhou Orife Energy Technology Co. Ltd.
Share on (1600627572034):
Product Overview
Description
◆ Specifications
Nominal Voltage | 12 V | ||||
Capacity (25℃) | 20HR(10.5V) | 9Ah | |||
10HR(10.5V) | 8.4Ah | ||||
1HR(9.60V) | 5.8Ah | ||||
Dimension | Length | 151±1.5mm (5.94inch) | |||
Width | 65±1mm (2.56inch) | ||||
Height | 94±1mm (3.70inch) | ||||
Total Height | 100±1mm (3.94inch) | ||||
Approx. Weight | 2.60kg (5.73lbs)±5% | ||||
Terminal type | T1/T2/T25 | ||||
Internal resistance (Fully charged, 25℃) | Approx. 19mΩ | ||||
Capacity affected by temperature (20HR) | 40℃ | 102% | |||
25℃ | 100% | ||||
0℃ | 85% | ||||
-15℃ | 65% | ||||
Self-discharge (25℃) | 3 month | Remaining Capacity: 91% | |||
6 month | Remaining Capacity: 82% | ||||
12 month | Remaining Capacity: 65% | ||||
Nominal operating temperature | 25℃±3℃(77℉±5℉) | ||||
Operating temperature range | Discharge | -15℃～50℃(5℉～122℉) | |||
Charge | -10℃～50℃(14℉～122℉) | ||||
Storage | -20℃～50℃(-4℉～122℉) | ||||
◆ Constant Current Discharge Characteristics (A, 25℃)
F.V/TIME | 5min | 10min | 15min | 30min | 60min | 2h | 3h | 4h | 5h |
9.60V | 34.2 | 21.6 | 17.1 | 9.54 | 5.85 | 3.2 | 2.3 | 1.84 | 1.56 |
9.90V | 33.2 | 21 | 16.7 | 9.35 | 5.76 | 3.18 | 2.28 | 1.83 | 1.55 |
10.2V | 31.8 | 20.1 | 16.1 | 9.06 | 5.62 | 3.15 | 2.27 | 1.81 | 1.54 |
10.5V | 30.4 | 19.2 | 15.5 | 8.84 | 5.5 | 3.1 | 2.25 | 1.8 | 1.53 |
10.8V | 28.7 | 18.1 | 14.7 | 8.52 | 5.34 | 3.02 | 2.18 | 1.75 | 1.48 |
◆ Constant Power Discharge Characteristics (Watt, 25℃)
F.V/TIME | 5min | 10min | 15min | 30min | 60min | 2h | 3h | 4h | 5h |
9.60V | 382 | 244 | 195 | 109 | 67.7 | 37.4 | 27.3 | 21.9 | 18.6 |
9.90V | 370 | 236 | 190 | 107 | 66.7 | 37.2 | 27.1 | 21.7 | 18.5 |
10.2V | 355 | 227 | 183 | 104 | 65 | 36.9 | 26.9 | 21.6 | 18.4 |
10.5V | 340 | 217 | 177 | 101 | 63.7 | 36.3 | 26.7 | 21.4 | 18.3 |
10.8V | 321 | 205 | 168 | 97.6 | 61.8 | 35.4 | 25.9 | 20.8 | 17.7 |
Note: The above characteristics data can be obtained within three charge/discharge cycles.
