Product Overview
Description
Item | VSL15 | VSL20 | VSL30 | VSL50 | VSL60 |
Rated Load(g) | 1500 | 2000 | 3000 | 5000 | 6000 |
Bucket Capacity(m3) | 0.6 | 1.3 | 1.7 | 3 | 3.3 |
Operating Weight(kg) | 3000 | 5600 | 9600 | 17100 | 18200 |
Engine | QUANCHAI | CUMMINS | CUMMINS | CUMMINS | CUMMINS |
Engine Model | 482-52M22 | 4BT3.9-C100 | 6BT5.9-C130 | 6CTAA8.3-C215 | 6CTA8.3-C240 |
Rated Power(kw) | 38 | 75 | 97 | 160 | 19 |
Rated Speed(r/min) | 2200 | 200 | 2200 | 2200 | 2200 |
Dump Height(mm) | 2850 | 3050\\3250 | 3100 | 3150 | 3448 |
Dump Distance(mm) | 790 | 885 | 1006 | 1250 | 1249 |
Wheelbase(mm) | 2100 | 2530 | 2660 | 3200 | 3200 |
Lifting,Lowering and Unloading Time(s) | 13 | 11.3 | 9.15 | 10.95 | 10.8 |
Max. Breakout Force(KN) | 43 | 48.87 | 127 | 170 | 204 |
Min. Turning Radius(mm) | 3400 | 4500 | 5097 | 6640 | 7020 |
Overall Dimension(mm) | 5200*1600*2550 | 6250*2090*2860 | 6890*2430*3070 | 7920*3050*3400 | 7965*3050*3470 |
1. The working device is optimized by computer, which makes the operation more portable and flexible and the movement more stable and reliable.
2. The rear-lift metal structure engine cover is adopted for the loader, which is durable and more convenient for maintenance.
3. The loader adopts high quality hydraulic piping and a reasonable layout, it also has high strength reserve gearbox, drive axle.
4. The loader has a heavy load frame and mature fixed-shaft transmission system, heavy-duty conditions overhaul cycle extended year-on-year.
