Product Overview
Description
Industrial X-ray inspection 3D CT
CT-200 system is acustomizable small- and medium-sized CT system.
It is a cost-effective X-rayDR/CT system specially designed for die casting and injection moldingindustries. CT-200 provides both X-ray 2D real-time imaging and 3D scanningimaging functions. With visual analysis software, it can realize the functionsof defect analysis, three-coordinate measurement, digital-to-analog comparison,wall thickness analysis, reverse engineering, and mold correction, etc. Thesystem can configure more than one types of low- and medium-energy X-ray sourcesas required by users. Characterized by high scanning accuracy and long life, itcan meet most laboratory installation conditions and is suitable for small andmedium-sized samples.
Specifications
X-RAY SOURCE |
| |
Maximum voltage |
| 225~450kV |
Maximum power |
| 150W |
Focal size |
| 2um |
FPD |
| |
Area |
| 427mm×427mm |
Pixel matrix |
| 3072×3072 |
Pixel size |
| 139um |
* Options |
| Multiple optional resolutions, visual field sizes |
Specimen stage |
| |
Measurements of testable samples |
| 600mm×600mm(Diameter × height) |
Sample load |
| 100kg |
* Options |
| Two optional load capacity designs |
Equipment |
| |
Measurements |
| 2800mm×1400mm×2010mm(L×W×H) |
Weight |
| 4500kg |
Scanning time |
| 10 min |
Reconstruction time |
| 6 min |
Advantages |
| Medium- and large-sized, medium- and high-density samples Scalable, customizable appearance and measurements |
Applications |
| Automotive, additive manufacturing, casting injection molding, lithium batteries, petroleum geotechnical |
