Algae Tubular Separator Centrifuge
US $6800
Industrial sea salt production centrifugal separator
- Category: Separation Equipment >>>
- Supplier: Jiangsu,Blovebird,Centrifuge,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
LWL Series Worm Screw Screen Centrifuge
Performance and Use:
Blovebird horizontal screen scroll centrifuge has the advantages of large production capacity, good solid phase dehydration, low energy consumption and light weight.
Widely used in chemical, food, pharmaceutical and mining industries, and is suitable for the separation of solid-phase suspensions containing coarse crystals and short fibers.
Especially suitable for separating suspension of easy dehydration and high concentration.
MAIN FEATURES
1. Strong pertinence to materials, the crystal size is between 0.05-10mm
2. Continuous operation, Screw unloading, Large production
3. The solid phase has low moisture content, good washing effect and high separation efficiency
4. Dedicated filter screen, material optional, filter screen thickness up to 0.5mm, longer service life
5. Stepless speed regulation of drum speed
6. Simple and reliable lubrication
7. Compact structure, easy operation and maintenance
8. Safety protection: speed detection, oil-free protection, motor overload and overheat protection, spiral zero differential protection.
★LWL series has hundreds of cases in the waste salt treatment industry, including sodium chloride, sodium sulfate, ammonium chloride, ammonium sulfate, ferric chloride, and ferrous chloride. In addition, we have rich experience in plant extraction (tea, ginkgo, iron powder, kudzu root, hemp leaves, etc.), magnesium sulfate, copper sulfate, sodium gluconate, sodium metabisulfite, marine snowmaking, and other industries. Welcome customers from related industries to inquire.
The improvements made by Blovebird in ammonium sulfate, ammonium chloride, ammonium thiocyanate, sodium chloride and other waste liquid salt extraction equipment:
--------------------------------------------------------------------------------------------------------------------------------------------------------
1. The feeding pipe device is improved, the cloth is more uniform, and the equipment operation is more stable;
2. The lubrication system is improved, the lubrication is more adequate and reasonable, and the bearing weight is increased;
2. The lubrication system is improved, the lubrication is more adequate and reasonable, and the bearing weight is increased;
3. Improve the bearing sealing system and adopt labyrinth oil seals to prevent mother liquid from entering the lubrication system;
4. The drum spiral is treated with nitriding and wear-resisting, and the service life is longer.
5. The discharging system is improved, and a scraper device is added to prevent the silo from accumulating.
WORKING PRINCIPLE
Under full speed operation: continuous feeding, washing, dewatering, unloading and other technological operations of the suspension.
The suspension enters the spiral cavity from the feed pipe, and enters the drum through the nozzle at the bottom of the screw head near the bottom of the cone.
Under the action of the centrifugal force field, the liquid phase in the slurry is separated by the creen set on the rotating wall When going out, the solid particles are trapped in the drum; at the same time, the solid particles in the drum move from the small end of the drum to the big end of the drum under the action of centrifugal force and the differential speed between the
The suspension enters the spiral cavity from the feed pipe, and enters the drum through the nozzle at the bottom of the screw head near the bottom of the cone.
Under the action of the centrifugal force field, the liquid phase in the slurry is separated by the creen set on the rotating wall When going out, the solid particles are trapped in the drum; at the same time, the solid particles in the drum move from the small end of the drum to the big end of the drum under the action of centrifugal force and the differential speed between the
spiral and the drum.
During the movement, the centrifugal force increases rapidly due to the increase of the rotation diameter. The solid phase changes from the high moisture content solid phase when it initially enters to the low moisture content solid phase when it is discharged from the drum, thus realizing automatic and continuous solid and liquid phase separation.
During the movement, the centrifugal force increases rapidly due to the increase of the rotation diameter. The solid phase changes from the high moisture content solid phase when it initially enters to the low moisture content solid phase when it is discharged from the drum, thus realizing automatic and continuous solid and liquid phase separation.
LWL Series Screw Screen Centrifuge has been successfully used in the following:
Adipic Acid | Potash | Rock Salt | Date Stones |
Salt Cake | lon Excgange Resin | Sodium Nitre | Polystyrene Alcohol |
Arsenic Triazole | Sodium Chloride | Sodium Perborate | Sodium Thiosulphate |
Ah-salt | Anth Racene | Nylon Chips | Copper Sulphate |
Naphthenic Sulfonic Acid Ester | Iron Sulphate Hepta Hydrate | Hops From Dichlorc Methare | Ammonium Thiosulphate |
Greaves | Sodium Chlorate | Citric Acid | Tarteric Acid |
Aminiacetic Acid | Aspirin | Oxalic Acid | Crystal Soda |
Gun Powder | Lactose | Sodium Sulphate | Potash Alum |
Regenerated Rubber | Sodium Formate | Polymethacrylate | Tin Sulphate |
Ammonium Persulphate | Bisphenol | Sodium Sulphite | Dinitro Methylarlin |
Gypsum | Managanese Sulphate | Polysyrene | Potash Solvent Residue |
Silver Nitrate | Sodium Gliconate | Sodium Tetraborate | Trisodium |
Ammonium Phosphate | Borax | Two Nitro Methylaniline | Extraction from Methanol |
Urotropin | Methyl Cellulose | Disodium Phosphate | Potassium Bica Rbonate |
Sodium Acetate | Sodium Metaborate | Potassium Lore | Zinc Sulphate |
Ammonium Sulphate | Calcium Formiate | Potassium Chloride | Potassium Bichromate |
Sodium Phosphate | Monosod lumphasphate | Polyvinyl Chloride | Potassium Pensuphate |
Sodium Ca Rbonate | Sodium Nitrate | Potassium Sulphate | Fungal Mycel |
--------------------------------------------------------------------------------------------------------------------------------------------------------
Structural Diagram
The drum/screw of the centrifuge can be customized in different angles according to customer requirements.
Material selection:
The material of the part in contact between the centrifuge and the material can be selected from stainless steel (304, 316L, 2205,
etc.), Hastelloy, titanium and other corrosion-resistant materials according to customer requirements.
Material selection:
The material of the part in contact between the centrifuge and the material can be selected from stainless steel (304, 316L, 2205,
etc.), Hastelloy, titanium and other corrosion-resistant materials according to customer requirements.
Configuration selection：
Explosion-proof configuration, gas-liquid separation device at the discharge port, washing device, vibration and main bearing temperature monitoring protection, etc.The standard cone angle of 20° is suitable for the separation of most materials
The 10° cone angle is suitable for separation processes that require heating and washing effects
0° barrel drum is suitable for the separation of ice crystals and filber derivatives
Customer Cases
Company：Jiangsu Victor Co., Ltd.
Material：Sodium chloride
Capacity：LWL350
Company：Pingxiang Xianwang Industrial Co., Ltd.
Material：Sodium chloride
Capacity：LWL450
Capacity：LWL450
Company：Hangzhou Jihua Jiangdong Chemical Co., Ltd.
Material：Ammonium sulfate
Capacity：LWL450
Capacity：LWL450
Company：Linhuan Coking Co., Ltd.
Material：Ammonium sulfate
Capacity：LWL450
Capacity：LWL450
Company：Heze Yuandong Qiangya Chemical Co., Ltd
Material：Ferric chloride
Capacity：LWL450
Capacity：LWL450
Company：Tangshan Siruier Chemical Co., Ltd.
Material：Ferrous chloride
Capacity：LWL450
Capacity：LWL450
Company：Linhuan Coking Co., Ltd.
Material：Ammonium sulfate
Capacity：LWL450
Capacity：LWL450
Company：Jiangxi Yongtong Technology Co., Ltd.
Material：Sodium sulfate
Capacity：LWL450
Capacity：LWL450
Company：Tangshan Zhongrun Coal Chemical Co., Ltd.
Material：Magnesium sulfate
Capacity：LWL350
Capacity：LWL350
Company：Zhengzhou Yuda Chemical Co., Ltd.
Material：Copper sulfate
Capacity：LWL450
Capacity：LWL450
Company：Kaidi Chemical Co., Ltd.
Material：Sodium gluconate
Capacity：LWL350
Capacity：LWL350
Company：Bangze Chemical Co., Ltd.
Material：Sodium pyrosulfite
Capacity：LWL530
Capacity：LWL530
Company：Zibo Huayan Chemical Co., Ltd.
Material：Sodium sulfate
Capacity：LWL450
Capacity：LWL450
Company：Dongjiang Environmental Co., Ltd.
Material：Sodium chloride
Capacity：LWL350
Capacity：LWL350
Company：Nantong Chenlong Chemical Co., Ltd.
Material：Ammonium chloride
Capacity：LWL450
Capacity：LWL450
Company：Shandong Aochuang Chemical Co., Ltd.
Material：Magnesium sulfate
Capacity：LWL630
Capacity：LWL630
Product Paramenters
Model | Drum Dia (mm) | Drum Length (mm) | Speed (r/min) | Factor | Feeding (m³/h) | Power (kw) |
200 | 200 | 176 | 4000 | 1790 | 0.5-1.5 | 3 |
250 | 250 | 208 | 3500 | 1712 | 1-5 | 4 |
350 | 350 | 287 | 3000 | 1762 | 3-15 | 11 |
450 | 450 | 356 | 2600 | 1700 | 3-18 | 22 |
530 | 530 | 405 | 2200 | 1434 | 6-20 | 30 |
630 | 630 | 496 | 1850 | 1205 | 10-30 | 37 |
800 | 800 | 525 | 1500 | 1008 | 15-40 | 55 |
1000 | 1000 | 664 | 1000 | 560 | 20-50 | 90 |
