China factory supply CNC Gantry Plasma Cutter plasma cutting machine gantry

Product Overview

Description

1.Technical Performance Specification

(1) Machinery parts

In order to cater to customers requirements of high speed and high accuracy,our company takes into account the machinery structures which may affect the performance of the machine when designing ,processing and manufacturing,including friction, backlash,rigidity,inertia and so on in a comprehensive way. And we also use the computer to analyze dynamic characteristics of machine.





(2) The electrical control parts

Electrical control parts of the CNC cutting machine consists of CNC system,electrical control system and step-by-step motor system. The CNC cutting system adopts modular structure which is reasonable,formal and with easy maintenance. It widely adopts integrated circuit which has the advantage of small size, stable performance.



(3) CNC Control System

Beijing Starfire CNC Control System 2012

1) A 7.5 -inch LCD display

2) USB interface

3) Coordinate axis number : 2

4) Compounding axis number:2

5) Maximum programming range: +99999.999mm

6) Minimum programming range: -99999.999mm





(4) Step-By-Step Motor System

1) The step motor has a mall size, large output torque and a quick response as well as easy installation, beautiful appearance.It uses a SPC as the position feedback and speed feedback element.

2) The driver is digital controlled, and has a power supply and control logic integrated modular structure.
