solar power inverter price 4500watts 48vdc 230vac hybrid solar inverter with 150A MPPT solar controller

Product Overview

Description

solar power inverter price 4500watts 48vdc 230vac hybrid solar inverter with 150A MPPT solar controller



Feature

1.Pure sine wave output inverter

2.The product is compact and beautiful, with 6.25 inch LCD display and touchable buttons

3.The utility input voltage range can be selected according to the requirements of the load (home appliance/PC)

4.Battery charging current can be set via LCD according to load requirements

5.Smart battery charging design makes the battery more fully utilized utility/battery priority input mode can be set via LCD display

6.Compatible with mains and generator inputs utility and PV complementary power supply loads to ensure maximum utilization of PV

7.Auto restart function when PV/utility recovers

8.Overload, high temperature, inverter output short circuit protection

9.Cold start function special mode for lithium battery to prolong the battery life

10.Support different communication way:RS232 / RS485 / WIFI / Blue tooth

11.WIFI monitoring and setting(optional)

12.Dust filter(optional)



Product Parameters





MODEL		MPS-VX 4.5KW	MPS-VX 6.5KW	MPS-VX 7.2KW
Rated Power		4500W	6500W	7200W
INPUT
Voltage		230VAC
Selectable Voltage Range		170-280VAC(for personal computers) 90-280VAC(for home appliances)
Frequency Range		50Hz/60Hz(Auto sensing)
OUTPUT
AC Voltage Regulation(Batt . Mode)		230VAC±5%
Surge Power		2* rated power for 5 seconds
Efficiency(Peak)PV to INV		97%
Efficiency(Peak)BAT to INV		94%
Transfer Time		10ms(for personal computers) 20ms(for home appliances)
Wave form		Pure Sine Wave
BATTERY&AC CHARGER
Battery Voltage		24VDC	48VDC	48VDC
Bulk Charging Voltage	Flooded Battery	29.2V	58.4V	58.4V
	AGM/GEL Battery	28.2V	56.4V	56.4V
Floating Charge Voltage		27Vdc	54Vdc	54Vdc
Overcharge Protection		32Vdc	63Vdc	63Vdc
Maximum charge current		150A	130A	150A
SOLAR CHARGER
MAX.PV Array Power		5500W	6500W	8000W
MPPT Range@ Operating Voltage		120-450Vdc
Maximum PV Array Open Circuit Voltage		450Vdc
Maximum Charging Current		150A	130A	150A
Maximum Efficiency		99%
PHYSICAL
Dimension. D*W*H(mm)		400*250*85mm
Net Weight(kg)		7.5kg
Communication Interface		RS485/RS232(Standard) WIFI(Optional)
OPERATING ENVIRONMENT
Humidity		5% to 95% Relative Humidity(Non-condensing)
Operating Temperature		0℃~50℃
Storage Temperature		-15℃~60℃







Product Link Skretch





Product details show











Product Processing

Product Packing
