Big Capacity Molding Machine Making Moulding Plastic Injection For Prefom Port 500 600Ton
- Category: >>>
- Supplier: Hunan Gladden Pharma Industries Co. Ltd.
Share on (1600633416475):
Product Overview
Description
Product Description
| Item | Unit | 300SeIII-PP |
| Screw diameter | mm | 85/94 |
| Theoretical shot volume | cc | 2776 |
| Shot weight (PP) | g | 2026 |
| Shot weight (PP) | oz | 76.7 |
| Length/Diameter ratio | L/D | 24 |
| Injection pressure | MPa | 126 |
| Injection rate | cm3/sec | 603 |
| Injection stroke | mm | 400 |
| Max. screw speed | rpm | 115 |
| Plasticizing capacity (PP) | g/s | 112.3 |
| Clamping force | ton | 300 |
| Max. daylight | mm | 1160 |
| Clamping stroke | mm | 500 |
| Distance btwn. Tie bars(W x V) | mm | 660*860 |
| Min mould dimension(W x V) | mm | 460*660 |
| Mould thickness range | mm | 300-660 |
| Ejector force | ton | 19.8 |
| Ejector stroke | mm | 180 |
| No. of ejector pins | unit | 15 |
| Main Power | kw | 73.3 |
| No. of heater zones | unit | 5+1 |
| Heater input power | kw | 62.75 |
| Ultimate capacity | kw | 137.05 |
| Current | A | 187.4 |
| Machine Dimensions | m | 8.4*1.8*2.1 |
| Net weight | ton | 14.4 |
| Oil filling capacity | L | 600 |
