KZ 8060/D Hualian Semi Automatic PP PET Strap Belt Pallet Bundling Strapping Machine For Carton Case
- Category: >>>
- Supplier: Hualian Machinery Group Co. Ltd.
Share on (1600637247281):
Product Overview
Description
Product Description
Description:
1. KZ-D series high-table automatic strapping machine is suitable for general objects
2. KZ-D series is ideally suited for general light products.
3. The tabletop of KZG series is equipped with rollers to ensure strapping can be achieved with less force.
4. KZ-D high table automatic strapping machine can be used in production line of which objects differ in size and irregular in shape,and it can achieve unmanned strapping together with power conveyor.
5. Can achieve unmanned strapping together with power conveyor.
6. Power belt tabletop and access transmission mechanism are adopted, with easy maintenance.
Features:
1. Adopt film, durable, efficient KZ-D mechanism as main body.
2. Adopt human-machine interface, PLC and fully digital manipulation to ensure easy size changeover and stable running.
3. Due to special design of strap feeding and withdrawal track, more straps are applicable and packing cost is lowered greatly
4. Oil-free maintenance, firm strapping, high speed and long use life.
1. KZ-D series high-table automatic strapping machine is suitable for general objects
2. KZ-D series is ideally suited for general light products.
3. The tabletop of KZG series is equipped with rollers to ensure strapping can be achieved with less force.
4. KZ-D high table automatic strapping machine can be used in production line of which objects differ in size and irregular in shape,and it can achieve unmanned strapping together with power conveyor.
5. Can achieve unmanned strapping together with power conveyor.
6. Power belt tabletop and access transmission mechanism are adopted, with easy maintenance.
Features:
1. Adopt film, durable, efficient KZ-D mechanism as main body.
2. Adopt human-machine interface, PLC and fully digital manipulation to ensure easy size changeover and stable running.
3. Due to special design of strap feeding and withdrawal track, more straps are applicable and packing cost is lowered greatly
4. Oil-free maintenance, firm strapping, high speed and long use life.
Product Paramenters
KZ-8060/D | KZD-8060/D | ||
Voltage (V/Hz) | AC380/50 | AC380/50 | |
Power (W) | 1000 | 1000 | |
Max. Strapping Size (W×H) (mm) | 800×600 (Standard type) | ||
Min. Strapping Size (W×H) (mm) | 80×50 | 270x120 | |
Strapping Speed (sec/pass) | <2..5 | ||
Strapping Force (N) | 25-700(adjustable) | ||
Plastic Strap Used (mm) | PP or PE strap. 9-15mm in width, 0.5-1.1mm in thickness | ||
Height of Table (mm) | 750 | 500 | |
External Dimensions (L×W×H)(mm) | 1400×620×1530 | 1400x630x1530 | |
Net Weight(kg) | 240 | 300 | |
Product packaging
Model | KZ-8060/D |
Pcs/CTN (pc) | 1 |
Package Type | W/C |
Gr. Wt. (kg) | 249 |
Length（CM） | 155.00 |
Width（CM） | 82.00 |
Height（CM） | 110.00 |
Single piece volume(CBM) | 1.398 |
Company Profile
FAQ
Q: Are you a factory or a trading company?
A: We are a factory manufacturing packaging&printing machines and we provide perfect OEM and after-sale service. We export machines to over 108 countries since 1995.
Q: Can you send me the video to show how the machine works?
A: Certainly, we have video of every standard machine and can send to you by Email or other way you want.
Q: How can I pay my order?
A: We accept T/T, Western Union, Alibaba Online Payment to pay.
Q: Do you have any certificate?
A:We have passed ISO9001:2008,ISO14001,OHSAS18001 and obtained CE certificate and BSCI certificate from UL.
Q: Why the model name of your machine same as the machine form other company?
A: Since these machines have long history and are very popular in the market, it may be indeed possible that some machine models are similar as others. What we may think is that the machine model does not make big difference. And the criteria for machines may depend on the technical support and quality of the machines.
Q: When your company was founded?
A: Hualian Machinery Group Co., Ltd. was established in 1989.
Q:How about your warranty?
A: Our warranty is 12 months. Normally, the general after-sale service may be as below:
1) The technical support is permanent.
2) The paid spares parts could be provided at any time.
3) We have dealers in some countries to offer compensable service.
Q: Why your price is higher than many suppliers in China?
A: Hualian is old and famous brand of packing machines and we offer machines in high quality and consummate service from inquiry to after-sale.
Q: Can you send me the video to show how the machine works?
A: Certainly, we have video of every standard machine and can send to you by Email or other way you want.
Q: How can I pay my order?
A: We accept T/T, Western Union, Alibaba Online Payment to pay.
Q: Do you have any certificate?
A:We have passed ISO9001:2008,ISO14001,OHSAS18001 and obtained CE certificate and BSCI certificate from UL.
Q: Why the model name of your machine same as the machine form other company?
A: Since these machines have long history and are very popular in the market, it may be indeed possible that some machine models are similar as others. What we may think is that the machine model does not make big difference. And the criteria for machines may depend on the technical support and quality of the machines.
Q: When your company was founded?
A: Hualian Machinery Group Co., Ltd. was established in 1989.
Q:How about your warranty?
A: Our warranty is 12 months. Normally, the general after-sale service may be as below:
1) The technical support is permanent.
2) The paid spares parts could be provided at any time.
3) We have dealers in some countries to offer compensable service.
Q: Why your price is higher than many suppliers in China?
A: Hualian is old and famous brand of packing machines and we offer machines in high quality and consummate service from inquiry to after-sale.
