2.5 ton diesel forklift with high exhaust and forklift parts double air filter Japanese engine

Product Overview

Description

  15ton4*4 wheel warehouse storage equipment /diesel forklift 15ton 3m for sale



1. The special all-round roller bearing the doorframe and prolong service life, improve reliability.



2. Adjust the load distribution, improve the stability and load capacity.



3. The door frame high strength wide view mast and two or three free all day promote the door frame of its scope. Highly choice, can be configured fork move, lateral and various appurtenances provided.



4. The instrument and seat beautiful reliable combination instrument, steering wheel and small pear-shaped handle all of human body engineering design, reflect people-oriented design thought.



5. Imported heavy KaShi high hfe braking system to ensure that the heavy than

braking, brake reliably.



6. Equipped with unique top oil cylinder, facilitate the customer maintenance operation.



7. Overloaded with high strength in drive to bridge the slow, and the planet type wheel edges to slow down, the more suitable for heavy and bad working conditions in the safe and reliable operation of homework.



8. Hydraulic steering system, the realization to light, small in turning radius, flexible steering, it is easy to operate.



9. With double pump confluence work hydraulic system, reduce oil consumption, energy consumption.



10. Wide view mast view is broad, easy to observe the driver.



11. All parts localization, cost-effective, accessories and general high to buy, the daily maintenance convenient.



12. Lifting height up to 3 meters, and can be designed according to customer requirements height.



13. The engine and hydraulic converter high quality diesel engine fuel injection allocation as the drive source (Japan, domestic engine can be according to users based), easy to type engine cover and highly effective hydraulic torque converter, fixed axis type mesh hydraulic power transmission, effective hang block guarantee the machine good working effect.



14. The strong power of diesel engine, reliable, economical.



15. Widely used in airports, ports, docks, stations, warehouse work strength great occasion for loading and unloading, and storage.



16. Hydraulic transmission, the planet type wheel edges reducer, stepless speed, simple operation.



17. Set limit limited pressure relief valve, prevent the operating error, reduce hydraulic system damage.



Specifications of lift truck equipment:

>STANDARD DIMENSIONS Model FD115 FD135 FD140 FD150 Overall height fork raised (with backrest)(mm) 5539 5884 5884 5884 Mast Lifting height(mm) 4000 Free lift(mm) 0 Overall height fork lowered (mm) 3539 3884 3539 3884 Backrest height (from upper face of forks)(mm) 1035 1035 1035 1035 Overall length (with forks)(mm) 5875 6030 6080 6340 Overall length (without forks)(mm) 4375 4530 4580 4840 Overall height(over head guard)(mm) 2835 2875 Overall width(mm) 2370 2450 Fork length(mm) 1500 Fork thickness(mm) 82 87 87 87 Fork width (mm) 170 200 200 200 Lateral for adjustment (outside of fork)(mm) 508-2012 Overhead-guard clearance (from face of sent)(mm) 1000 Coupler height(mm) 630 630 630 630 Fork overhang(mm) 757 796 796 804 Rear overhang(mm) 819 936 986 936 Wheel base(mm) 2800 2800 3100 Tread(front)(mm) 1760 1765 Tread(read)(mm) 1930 1890 Min under-clearance (bottom of mast)(mm) 275 260 Min turning radius(mm) 4080 4160 4210 4550 Min intersecting aisle ( °) 3580 3620 3620 3780 Tilt angles(forward backward)(mm) 6/12 Specification
Model	FD115		FD135		FD140		FD150
Load Capacity(kg)	11500		13500		14000		15000
Load Center(mm)	600
Power Type	DIESEL
Tire Type	Pneumatic
Lifting Speeds(With Load/Without Load)(mm/s)	320/340		290/310		290/310		280/310
Lowering Speeds(With Load/Without Load)(mm/s)	<600>=300
Max Driving Speeds(km/h)	25/27	24/26	25/27	25/27	25/27	25/27	24/26	24/27
Max Gradebility(%)	20		15
Brake Distance(m)	<=7
Wheel (Front/Rear)	4/2
Tire (Front/Rear)	10.00-20-16PR 10.00-20-16PR		12.00-20-18PR 12.00-20-18PR		12.00-20-18PR 12.00-20-18PR		12.00-20-18PR 12.00-20-18PR
Weight Distribution With Load(Front/Rear)(kg)	24450/2450	24510/2390	28250/2750	28290/2710	28550/3200	28610/3140	29450/3350	29490/3310
Weight Distribution Without Load(Front/Rear)(kg)	7470/7930	7520/7880	7880/9620	7920/9580	7980/9770	8020/9730	8460/9340	8490/9310
Battery Voltage/Capacity(V/Ah)	2x12/150
Service Brake	AIR-BOOST TYPY
Parking Brake	SHDE-DRUM TYRE	DISC BRAKE	SHDE-DRUM TYRE	DISC BRAKE	SHDE-DRUM TYRE	DISC BRAKE	SHDE-DRUM TYRE
Internal Combustion Engine Model	CA6DE1	Mitsubishi 6D16TLE2C EUROII	Dachai CA6DE1	Mitsubishi 6D16-TLE2C EUROII	Dachai CA6DE1	Mitsubishi 6D16-TLE2C EUROII	Dachai CA6DE1	Mitsubishi 6D16-TLE2C EUROII
Internal Combustion Engine Fuel Tank Capacity(L)	240
Transmission Number Of Speed Fwd/Revs type	Mechanical Shift	Electric shift	Mechanical Shift	Electric shift	Mechanical Shift	Electric shift	Mechanical Shift	Electric shift
Total Weight(KG)	15400		17500		17750		17800



FAQ
Any questions, welcome to contact us, we will be always help you and support you.
Q: May I know how soon I can get the machine after I transfer the deposit?
A: Usually, if the quantity is less than 20 units, we can finish the production in 15-20days.
We will try our best to offer the machines to you as soon as possible.
Q: How long the product warranty period?
A: The product warranty period is 18 months or 2000 hours.
Q:How can i become a distributor of Vmax?
A: We have been engaged in this industry for more than 20years, Our hot products sold
at home and abroad by our own foreign trade department and some trading company.
