Main Parameter | ||||||||||||
Lifting Capacity | t | 5.0-16.0 | 20/5-32/5 | (5+5)-(25+25) | ||||||||
Span | m | 10.5-31.5 or Designed | ||||||||||
Max. Lifting Height | m | 16 | 16.0-18.0 | 12.0-18.0 | ||||||||
Speed | Hoisting | Electromagnetic | m/min | 16.4-19.9 | 7.8-19.29 | 7.8-15.3 | ||||||
Aux Hook | 19.5 | |||||||||||
Trolley Travelling | 39.5-45 | 42.4-45.9 | 84.7-91.9 | |||||||||
Crane Travelling | 101.4-116.8 | 86.6-115.0 | 86.6-112.5 | |||||||||
Motor | Hoisting | Electromagnetic | KW | 22-45 | 42-55 | 26-85 | ||||||
Aux Hook | 13-15 | 34-10/110 | ||||||||||
Trolley Travelling | 1.5-3.7 | 5.5-6.3 | 2.5-6.3 | |||||||||
Crane Travelling | 2*5.5-2*11 | 2*8.5-2*15 | 2*4-2*18.5 | |||||||||
Weight | Trolley | t | 2.38-5.55 | 8.93-11.63 | 6-17.1 | |||||||
Total | 13.4-42.3 | 24.3-55.27 | 17.2-71.8 | |||||||||
Electro-magnetic Disk | Model | MW5-90L/165L | LMC-240A | |||||||||
Attracting Weight | t | 4.2-12.5 | ||||||||||
Self-weight | 0.8-3.2 | 7 | ||||||||||
Diameter | mm | 900-1650 | ||||||||||
Max. Wheel Load | KN | 74.5-213 | 115-335 | 108-483 | ||||||||
Working Group | A6 | A6 | A5-A6 | |||||||||
Steel Track Recommended | 38-43kg/m QU70 | 50kg/m QU70 | P18-P80 QU70-100 | |||||||||
Power Supply | 3P AC 380V 50Hz | |||||||||||

Packaging Details: | Packaging: 1. Electric parts are packed in iron box to reduce distortion in conveying; 2. Steel structures are fastened by bolts. Land Transportation & Shipping: 1. If the size of whole crane are suitable for container ship, usually by container; 2. If the size is too big, usually by bulk ship or by container after truncation; 3. Transport ways are based on reducing cost for you and keep the crane performance! |
Delivery Day : | Within 150 work days after receiving the deposit |
