Быстрое производство сырья 50 1500 сетка из фрезерованного стекловолокна в порошке для ПТФЭ

Product Overview

Description

fast production raw material 50-1500  mesh milled glass fiber powder for PTFE



This kind of milled E-glass fiber was made from E-glass chopped strand by ball mill,with procedures of wet grinding,drying, screening. used for reinforcement of unsaturated resin, epoxy and phenolic resins. also it can Improve foaming power for coating.Which has fast impregnation,good dispersion, less wool, making material has excellent mechanical properties.The finished products own bright brilliance and color. The product meet the ROHS standard.
DATASHEET:

SPECIFICATIONS	AVERAGE VALUE
Model:	MEF-13-100
Color	white
Glass type	e-glass
Mesh	50-1000
Fiber Diameter	13micron
Fiber Length	50micron
Aspect Ratio	3.8:1
Bulck Density	0.66g/cc
Moisture Content	<1.5%
Loss of Ignition	<1%
Alkali content/R2O(%)	≤0.80
Sizing	Silane
Contamination	Free from dirt,lumps,unmilled fiber

TERMINAL MARKET:
BMC molded products widely used in transportation, construction, electrical, chemical and other fields, for the production of auto parts, insulation materials, switch boxes, electrical panels.



STORATE:
The E-glass Chopped Strand should be stored in a dry place,preferably at room temperature and 50-70% relative humidity.



PACKAGING:
Products using woven PP bags with inner plastic bag, cardboard boxes,Big bags for packaging. Woven PP bag each net weight 25KG, Big bag each net weight 500-900 kg.Packing can be customized according to special requirements.

e mixture of e-glass chopped strand and phenolic resin, the material was widely used in automobiles, home appliances, electronic appliances, sports equipment, infrastructure and other fields.



STORAGE:



The E-glass Chopped Strand should be stored in a dry place,preferably at room temperature and 50-70% relative humidity.



PACKAGING:



Products using paper-plastic bags,octabin,Big-



Bag.paper-plastic bag each net weight 25KG,



Octabin each net weight 700-900kg,Big bag



each net weight 500-900 kg.Packing can be



customized according to special requirements.

Product item Images



  Production process

                                         E-type glassfiber chopped strand PRODUCTION PROCESS





  E-type glassfiber chopped strand BRIEF INTRODUCTION



E-type glassfiber chopped strand  for bulk moulding compounds (BMC) was cut from E-glass roving,treated by silane-based coupling agent and special sizing formula, has good compatibility with polyester resins.



E-type glassfiber chopped strand PRODUCT CHARACTERISTICS



chopped strand for bulk moulding compounds (BMC)with property:high integrity



chopped strand for bulk moulding compounds (BMC) with property:good distribution in BMC paste



chopped strand for bulk moulding compounds (BMC) with property:good processing,



chopped strand for bulk moulding compounds (BMC) with property:good mechanical properties.



E-type glassfiber chopped strand PRODUCT SPECIFICATIONS:



Type of glass	:	E	Size content %	:	1.40 ± 0.20
Filament diameter (µ)	:	Nom.11	Flow properties	:	Very good
Moisture content %	:	max. 0.10	Resin compatibility	:	Polyester
Coupling agent	:	Silane	Chopped length (mm)	:	4.5
	This model of fiberglass chopped strand is produced conforming ISO 9001: 2000



E-type glassfiber chopped strand  PRODUCT PACKAGING



Packaging Item	Net weight (kg)	Number of  bags on pallet	Pallet size (cm)	Pallet  height (cm)	Pallet net  weight (kg)
Paper-plastic Bag	25	36 / 40	110x110	105	900 / 1000
Octabin	--	1octabin	112x112	105	800
Big Bag	--	1 big bag	110x110	105	900
