Factory price thermal flow switch oil water flow switch
US $1.90-$2.40
One stop Service Steel Pharmaceutical Industries Water Differential Pressure Integrated Electronic Flow Switch
- Category: Flow Switches >>>
- Supplier: Shanghai,Joann,Water,Tech,Co.,Ltd.
Share on:
Product Overview
Description
Measuring medium range | Water: 3 - 300 cm/s; |
Gas: 200 -300 cm/s; | |
Oil: 3 -300 cm/s | |
precision | ± 1 - ± 10 cm/s |
Stable time | 3 minutes after startup |
pressure | ＜100 Bar |
Medium temperature | －20 to 80 ℃ |
thread | G1/2，G1/4 A variety of external threads (customizable) |
The output signal | PNP/NPN/relay/（4…20mA) |
The power supply | 24VDC/85-265VA（50…60Hz) |
Sensor length | 15/20/30/50mm(customizable) |
Current consumption | <100mA |
Set up the | Button to set |
The response time | 5 (2-15) s |
Maximum change rate of medium temperature | 300 K/min |
The output protection | Reverse/short-circuit/overload |
Protection grade | Ip67 |
Connection mode | M12Connector (cable 1m or custom) |
The material | ANSI316L |
relay | 30VDC/5A，220VAC/5A |
current | 250mA |
Q: Are you the final manufacturer?
A: Yes, We are manufacturer .
Q: How to make payment?
A: We accept T/T , Credit card and West Union.
Q: Could we visit your factory?
Q:Do you have any discount?
A:Yes, if you buy large quantity, please contact us or send email, we will give you a big discount.
Q: What is your delivery time?
A: It is about 5-7 working days since the payment confirmed . If the quantity more than 100pcs , it will need extra 10-20 working days.
Q: How long is the warranty of your products ?
A: 1 years warranty.
A: Yes, We are manufacturer .
Q: Do you offer the OEM order ?
A: Yes, we can offer OEM service and label according to your requirements.
A: Yes, we can offer OEM service and label according to your requirements.
Q: How to make payment?
A: We accept T/T , Credit card and West Union.
Q: Could we visit your factory?
A: Yes, Sincerely invite you to visit our factory.
Q:Do you have any discount?
A:Yes, if you buy large quantity, please contact us or send email, we will give you a big discount.
Q: What is your delivery time?
A: It is about 5-7 working days since the payment confirmed . If the quantity more than 100pcs , it will need extra 10-20 working days.
Q: How long is the warranty of your products ?
A: 1 years warranty.
