Product Overview
Description
Product Information
| Item NO. | Bending raduis | Crossbar width | Inner height*Inner width | Outer height*Outer width | pitch | Weight per meter |
HQ38 bridge type plastic cable chain | 75/100/125/150/200 | 75 | 39.5*76 | 65*108 | 70 | 2.57kg/m |
| 100 | 39.5*101 | 65*133 | 2.72kg/m | |||
| 150 | 39.5*151 | 65*183 | 3.05kg/m | |||
| 200 | 39.5*201 | 65*233 | 3.35kg/m | |||
| 250 | 39.5*251 | 65*283 | 3.66kg/m | |||
| 300 | 39.5*301 | 65*333 | 3.96kg/m | |||
| 350 | 39.5*351 | 65*383 | 4.29kg/m | |||
| 400 | 39.5*401 | 65*433 | 4.59kg/m | |||
HQ48 bridge type plastic cable chain | 150/200/250/280/400 | 75 | 48.8*76 | 74*110 | 80 | 2.98kg/m |
| 100 | 48.8*101 | 74*135 | 3.08kg/m | |||
| 150 | 48.8*151 | 74*185 | 3.4kg/m | |||
| 200 | 48.8*201 | 74*235 | 3.66kg/m | |||
| 250 | 48.8*251 | 74*285 | 3.92kg/m | |||
| 300 | 48.8*301 | 74*335 | 4.18kg/m | |||
| 350 | 48.8*351 | 74*385 | 4.46kg/m | |||
| 400 | 48.8*401 | 74*435 | 4.7kg/m | |||
HQ58 bridge type plastic cable chain | 150/200/250/300/400 | 100 | 59.5*100.2 | 89.76*140.2 | 90 | 3.85kg/m |
| 150 | 59.5*150.2 | 89.76*190.2 | 4.1kg/m | |||
| 200 | 59.5*200.5 | 89.76*240.2 | 4.45kg/m | |||
| 250 | 59.5*250.2 | 89.76*390.2 | 4.71kg/m | |||
| 300 | 59.5*300.2 | 89.76*340.2 | 5.04kg/m | |||
| 350 | 59.5*350.2 | 89.76*390.2 | 5.4kg/m | |||
| 400 | 59.5*400.2 | 89.76*440.2 | 5.63kg/m | |||
HQ68 bridge type plastic cable chain | 200/250/300/400/500 | 100 | 68*100.2 | 98.45*143.2 | 100 | 4.74kg/m |
| 150 | 68*150.2 | 98.45*193.2 | 5kg/m | |||
| 200 | 68*200.2 | 98.45*243.2 | 5.28kg/m | |||
| 250 | 68*250.2 | 98.45*393.2 | 5.52kg/m | |||
| 300 | 68*300.2 | 98.45*343.2 | 5.82kg/m | |||
| 350 | 68*350.2 | 98.45*393.2 | 6.16kg/m | |||
| 400 | 68*400.2 | 98.45*443.2 | 6.36kg/m | |||
HQ88 bridge type plastic cable chain | 200/250/300/400/500 | 102 | 92*102 | 135*146 | 128 | 5.5kg/m |
| 152 | 92*152 | 135*196 | 5.5kg/m | |||
| 202 | 92*202 | 135*246 | 6.2kg/m | |||
| 252 | 92*252 | 135*296 | 6.5kg/m | |||
| 302 | 92*302 | 135*346 | 6.8kg/m | |||
| 352 | 92*352 | 135*396 | 7.2kg/m | |||
| 402 | 92*402 | 135*446 | 7.51kg/m |
Hot Products
Product Application
Product Process
About us
Certification
FAQ
Q: Are you trading company or maunfacture ?
A: We are maunfacture . Our company integrated the research $ design production and sales into a whole.
Q:How long is your delivery time.
A: Generally it is 5~7 days if goods are in stock. or it is 7~15 days if the goods are not in stock . It is according to quantity
Q: Do you provide sample ? is it free or extra?
A:Yes . We provide samples for free
Q: What is your terms of payment?
A: payment ≤1000 USD 1000% in advance payment ≥ 1000USD 50%T/T in advance , balance before shipment.
Q: Do you offer custom service?
A:Yes . We will customize it according to your requirement
