Hantek Dpo6102b Fluorescent Oscilloscope 2ch 100mhz 1 Gsa/s Real time Sample Rate Waveform Generator
- Category: >>>
- Supplier: Shenzhen Kuongshun Electronic Business Department
Share on (1600642138568):
Product Overview
Description
Product Description
Hantek Dpo6102b Fluorescent Oscilloscope 2ch 100mhz 1 Gsa/s Real-time Sample Rate Waveform Generator
Six in one oscilloscope:2 channels oscilloscope+16 channels logic analyzer+2 channels waveform generator+digital voltmeter+serial
protocol analyzer+FFT spectral analysis.
60 000 wfms/s (dots display)/400,000 wfms/s (dots display quick acquisition mode) waveform capture rate.
Segmented acquisition function,support to capture up to 80,000 sections. 256 grade color display.
Up to 16 kinds of trigger functions, including 5 kinds of protocol triggers.Supply 5 serial decoding option.
1 GSa/s real-time sample rate of the analog channels; 64 Mpts standardmemory depth.
2-channe signal source,13 kinds of waveforms inside,4 sets of arbitrary waveforms,200M sample rate,8Kpts waveform length.
1 GSa/s real-time sample rate of the digital channels.
200 MHz, 100 MHz and 80 MHz analog channel bandwidth.
Low base noise, 500uV/div to 10 V/div ultra-wide vertical dynamic range.
7 inch WVGA capacitive touch screen,(800*480) TFT , with ultra-wide screen, vivid picture, lowpower consumption and long service
life.
Auto measurement of 42 kinds of waveform parameters (with statistics).
5 bits digital voltage meter and 6 bits hardware frequency indicator function.
Bode diagram function(the oscilloscopes with signal source function can use).
Multiple waveform math operation functions[MATH].Event search function.
Standard interfaces: USB Device, USB Host, LAN,Optional interfaces: HDMI ,UART
Conform to LXI CORE 2011 DEVICE class instrument standards; enable quick,economic and efficient creation and reconfiguration of
test system.Supports remote command control.
