Microsensor 4~20mADC ATEX Gas Pressure Transmitter 35MPa Piezoresistive Absolute Natural Gas Pressure Transmitter MPM489FL
- Category: Pressure Transmitters >>>
- Supplier: Micro,Sensor,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
Product Name | ATEX Pressure Transmitter |
Model | MPM489 |
Weight | 0.2kg |
Process connection | • M20*1.5 male waterline seal (or on your demand) |
Output signal | • 4mA~20mA DC(2-wire); • 0/1V~5/10V DC(3-wire); • 0.5V~2.5/4.5V DC(3-wire) |
Load | <(U-11)/0.02Q(2-wire); >10k(3-wire); >10k(3-wire) |
Housing protection | IP65 |
Electrical connection | DIN43650 plug or cable(1.5m) |
Power supply | 11V~28VDC; 11V~28VDC; 3.3/5V DC |
Storage temp. | -40℃~120℃; -20℃~85℃ (Cable) |
Application temp. | -30℃~80℃; -10℃~60℃ (Exia); -20℃~60℃ (Exd); -10℃~70℃ (Cable) |
Material | Housing: stainless steel 304 Sensor housing: stainless steel 304 Diaphragm: stainless steel 316L Sealed-ring: Viton Plug housing: plastic Cable: Φ7.5mm Polyethylene Special Cable |
FAQ
Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer since 1971 on Pressure/ Level/ Temperature/ Flow transmitters with 4~20mA, Hart, Rs485 & Modbus protocols, pressure sensors with SDI, I2C, 4~20mA, 0.5~4.5V and etc, and wireless IOT measurement transmitters. We provide high-quality products with high competitive factory prices.
Q: What's your quality control system?
A: As an ISO9001:2008 certificated manufacturer, we have a strict quality control system, and each product is done with fatigue testing, calibration, temperature compensation before shipment. High quality is guaranteed.
Q: Is there MOQ with your product?
A: We have no MOQ limits, 1pc for testing is acceptable.
Q: Do you provide customized products?
A: Yes, we can print your logo on our products; OEM, ODM & customization are welcomed.
Q: What is the warranty of your products? And after-sales service?
A: Our warranty time is 12 months after shipment, and our after-sales will respond with your questions in 24hrs, remote
instruction by PC network is always available.
Q: What is the lead time of your product?
A: We are a factory, our lead time is always within 10~15 working days for products without customization, but lead-time will vary based on different products. You can check detailed lead-time with our sales.
Q: What international certificates do you have for your products?
A: We have CE, RoHS, UL, ATEX as well as ship-use DNV, etc.
